17
Introduction
INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER
Seat belt warning light
High beam indicator
Turn signal indicator
ABS warning light
Parking brake & Brake fluid warning light
Engine oil pressure warning light
AWD system warning light (if equipped)
AWD LOCK indicator (if equipped)
ESC indicator
ESC OFF indicator
Malfunction indicator
Air bag warning light
Cruise indicator
Cruise SET indicator
Immobilizer indicator (if equipped)
Tailgate open warning light
Low fuel level warning light
* For more detailed explanations, refer to “Instrument cluster” in section 4.
Charging system warning light
Low windshield washer fluid level warning light
A050000AEN-EU
Door ajar warning light
Key out indicator (if equipped)
KEY
OUT
AWD
LOCK
AIR
BAG
ESC
ESC
OFF
TPMS (Tire Pressure Monitoring System) malfunction
indicator
Low tire pressure telltale
Low tire pressure position telltale
EN hma 1.qxd 11/27/2006 6:32 PM Page 7
