23
Your vehicle at a glance
INSTRUMENT PANEL OVERVIEW
OBH019002N
B020000ABH-EU
1. Instrument cluster.............................4-47
2. Horn .................................................4-38
3. Driver’s front air bag.........................3-44
4. Wiper/Washer...................................4-80
5. Ignition switch or Engine start/stop
button*.........................................5-4, 5-7
6. Climate control system.....................4-87
7. Digital clock ....................................4-106
8. Hazard warning flasher switch..4-74, 6-2
9. Shift lever .........................................5-11
10. Central control panel*...................4-110
11. Seat warmer or Climate control seat*
..................................................3-7, 3-8
12. Passenger’s front air bag ...............3-44
* : if equipped
