Quick Reference Guide I 19
CLIMATE CONTROL
1 8 I Quick Reference Guide
DEFOGGING
/
DEFROSTING
3. Set the fan speed to
the highest speed.
2. Select warmest
temperature.
1. Press the front defrost
button.
AIR INTAKE CONTROL
SYSTEM OFF
Pressing the OFF button will
place the system in the OFF mode.
t'SPOUCMPXFSXJMMUVSOPGG
t0VUTJEFGSFTIBJSQPTJUJPO
will be selected.
t7FOUFEBJSXJMMCFBUMBTUTFU
temperature.
Automatically controls the
modes, fan speeds, air intake
and air-conditioning functions.
AUTOMATIC HEATING /
AIR CONDITIONING
10
SYNC button
(sync driver and passenger front
air temperature)
11
Air intake control button (Outside air)
12
Air intake control button
(Recirculated air)
13
Climate information
screen selection button
14
Mode selection button (Passenger)
15
Air intake control button
16
Rear temperature
control thumbwheel
17
Rear vent ON/OFF thumbwheel
1
Driver’s temperature control knob
2
Fan speed control button
3
OFF button
4
AUTO (automatic control) button
5
Mode selection button (Driver)
6
Air conditioning button
7
Front windshield defrost button
8
Rear window defrost button
9
Passenger’s temperature
control knob
Front Rear
Type A
Type B
1
1
10
10
9
9
8
8
12
15
7
7
11
14
4
4
6
6
3
3
2
2
5
5
13
13
16 17
When cabin humidity and carbon dioxide levels increase while Climate
Control is off, fresh air will be circulated into the cabin.
Please refer to the Owner's Manual for more information.
Changing the direction
of the air flow as follow.
SMART VENT
MODE SELECTION
GENESIS
Outside(fresh) air position
(type B) (light off)
Recirculated air position
Outside(fresh) air position
(type A)
NOTE: To reduce the glass fogging and improve visibility, keep the interior
surface of the windshield clean by wiping it with a clean cloth and glass
cleaner. In addition, select air intake control to the outside (fresh) air position
whenever possible while operating the vehicle.
