3-57
Convenient features of your vehicle
3
Tachometer
The tachometer indicates the approxi-
mate number of engine revolutions per
minute (rpm).
Use the tachometer to select the correct
shift points and to prevent lugging and/or
over-revving the engine.
Do not operate the engine within the
tachometer's RED ZONE. This may
cause severe engine damage.
Engine coolant temperature
Gauge
This gauge indicates the temperature of
the engine coolant when the ignition
switch or Engine Start/Stop button is ON.
NOTICE
OAD045105
■ Conventional / Supervision cluster (Type A, B)
■ Supervision cluster (Type C)
OAD046105N
OAD045106
■ Conventional / Supervision cluster (Type A, B)
■ Supervision cluster (Type C)
OAD046106N
