Table 6. Adapter slot priorities and maximum adapters supported in the EMX0 PCIe3 expansion drawer
(continued)
Feature
code
Description EMX0 PCIe3 expansion drawer
Slot priorities
1
Maximum number of adapters
supported
2
AIX
®
Linux IBM i
EN2A PCIe3 16 Gb 2-port Fibre
Channel adapter (FC EN2A and
FC EN2B; CCIN 579D); Adapter
part number: 02JD564
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 6 6
1
The slot priority sequence is based on a EMX0 PCIe3 expansion drawer congured with two PCIe3
6-slot fanout modules.
2
The maximum number of adapters supported per PCIe3 6-slot fanout module.
3
If you have a CCIN 50CB PCIe3 6-slot fanout module, the FC EC2S and FC EC2U adapters are only
supported in slots C2 and C5. If you have a CCIN 50CD PCIe3 6-slot fanout module, the FC EC2S and FC
EC2U adapters are supported in slots C1 through C6, but only four FC EC2S and FC EC2U adapters can
be in SR-IOV mode at a time.
Related procedures for adapter placement
Find procedures that are related to adapter placement rules and slot priorities.
Finding the current system conguration in IBM i
You can use the System Service Tools in the IBM i operating system to nd the current system
conguration.
Before you begin
Before you begin, you must know the location codes of the PCI adapter slots in the system with which you
are working.
About this task
To nd the current system conguration, start an IBM i session and sign on. If you have more than
one system, start a session on the system that is being upgraded and for which you have service tools
authority.
To nd the current system conguration, complete the following steps:
Procedure
1. Type strsst on the command line of the Main Menu and then press Enter.
2. Type your service tools user ID and service tools password on the Start Service Tools (STRSST) Sign
On display and then press Enter.
3. Select Start a service tool from the System Service Tools (SST) display and then press Enter.
4. Select Hardware service manager from the Start a Service Tool display and then press Enter.
5. Select Packaging hardware resources (system, frames, cards) from the Hardware Service
Manager display and then press Enter.
6. Type 9 on the System Unit line and then press Enter.
7. Select Include empty positions.
Adapter placement for the 9040-MR9
15
