IBM iSeries 270 Analyze Hardware Problems (System Reference Codes

Reference Code Description/Action Perform all actions before exchanging Failing Items Failing Item
8FF0 Information only, no service action required
Service processor error log entry.
If the secondary refcode is 806A, a successful
download of control panel code has occured.
If the secondary refcode is 8EEE, one of the following
conditions may have occured.
Operation was successful but current
keylock position was not in Auto or normal.
The Time-of-Day (TOD) chip had to be reset
due to an invalid power-up state. TOD
requests will not work successfully until
a write TOD is done (CHGSYSVAL QDATE).
Timed-Power-On request has been acknowledged.
Power on sequences must be set for valid months,
days, hours, minutes, and seconds, for future
times, and for times when the system will be
powered off.
8FF1 System down, condition reported
Table 2. Service Processor Failing Items Details
Failing Item Description Document Description
AJDG301 Licensed Internal Code Service Functions; APAR or LICTR
AJDGP01 Service processor Licensed Internal Code Service Functions; APAR or LICTR
ALTINTF System bus Problem Analysis; Symbolic FRU Isolation
AUSTIN0 RESERVED - Austin Only code - flash update
by diskette
Problem Analysis; Symbolic FRU Isolation
BACKPLN Back Plane Unit Problem Analysis; Symbolic FRU Isolation
BUS1 System bus Problem Analysis; Symbolic FRU Isolation
CECPWR Power supply Problem Analysis; Symbolic FRU Isolation
CLCKCRD Clock Card Problem Analysis; Symbolic FRU Isolation
CLKCARD Clock Card Problem Analysis; Symbolic FRU Isolation
CTLPNL Control Panel, or the interface to the Control
Panel
Problem Analysis; Symbolic FRU Isolation
HSLCTLR System processor card Problem Analysis; Symbolic FRU Isolation
IOPWR Power Supply Problem Analysis; Symbolic FRU Isolation
IPLINTF System bus Problem Analysis; Symbolic FRU Isolation
JTPORT System Interconnect cable, connection or
interposer card
Problem Analysis; Symbolic FRU Isolation
LSMEDIA Tape, DASD or Optical Media Problem Analysis; Symbolic FRU Isolation
MSTORE Main storage cards Problem Analysis; Symbolic FRU Isolation
OPUSR Operator/User Error System Operations: Operator’s Guide SC41-8082
PROC System processor card Problem Analysis; Symbolic FRU Isolation
A1xx, B1xx
200
iSeries: iSeries 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Analyze Hardware Problems (System Reference
Codes)
