Table 59. IOA, and device address information for running IBM i (continued)
Position Possible failing item DSA (BBBBCcbb) Unit address
Un-P2-C9-D7 IDE drive 1 0200-20-00 (primary)
0220-20-00 (secondary 1)
0240-20-00 (secondary 2)
0260-20-00 (secondary 3)
000000FF
8412-EAD, 9117-MMC, 9117-MMD, 9179-MHC, or 9179-MHD addresses
You can cross-reference a disk drive physical location code to the address.
Use the address to find the location for the system, and then go to “8412-EAD, 9117-MMC, 9117-MMD,
9179-MHC, or 9179-MHD” on page 73 to find additional location information.
Table 60. IOA and device address information for running IBM i
Position Possible failing item DSA (BBBBCcbb) Unit address
Un-P2-C9-T1 Embedded SAS
controller
0200-20-00 (primary)
0220-20-00 (secondary 1)
0240-20-00 (secondary 2)
0260-20-00 (secondary 3)
Not applicable
Un-P2-C1 PCI adapter 0204-00-00 (primary)
0224-00-00 (secondary 1)
0244-00-00 (secondary 2)
0264-00-00 (secondary 3)
Not applicable
Un-P2-C2 PCI adapter 0205-00-00 (primary)
0225-00-00 (secondary 1)
0245-00-00 (secondary 2)
0265-00-00 (secondary 3)
Not applicable
Un-P2-C3 PCI adapter 0206-00-00 (primary)
0226-00-00 (secondary 1)
0246-00-00 (secondary 2)
0266-00-00 (secondary 3)
Not applicable
Un-P2-C4 PCI adapter 0201-10-00 (primary)
0221-10-00 (secondary 1)
0241-10-00 (secondary 2)
0261-10-00 (secondary 3)
Not applicable
178 Finding parts, locations, and addresses
