Page #37 background image
Table 6. FRU location (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
Memory card 1 - DIMM 2 Un-P1-C18-C2 Yes Note: The DIMM
fault and identify
LED is not visible
when the system
is in the service
position.
Memory card 1 - DIMM 3 Un-P1-C18-C3 Yes
Memory card 1 - DIMM 4 Un-P1-C18-C4 Yes
Memory card 1 - DIMM 5 Un-P1-C18-C7 Yes
Memory card 1 - DIMM 6 Un-P1-C18-C8 Yes
Memory card 1 - DIMM 7 Un-P1-C18-C9 Yes
Memory card 1 - DIMM 8 Un-P1-C18-C10 Yes
Memory card 2 Un-P1-C17 Yes See Memory
modules.
Memory card 2 - DIMM 1 Un-P1-C17-C1 Yes
Memory card 2 - DIMM 2 Un-P1-C17-C2 Yes Note: The DIMM
fault and identify
LED is not visible
when the system
is in the service
position.
Memory card 2 - DIMM 3 Un-P1-C17-C3 Yes
Memory card 2 - DIMM 4 Un-P1-C17-C4 Yes
Memory card 2 - DIMM 5 Un-P1-C17-C7 Yes
Memory card 2 - DIMM 6 Un-P1-C17-C8 Yes
Memory card 2 - DIMM 7 Un-P1-C17-C9 Yes
Memory card 2 - DIMM 8 Un-P1-C17-C10 Yes
Memory card 3 Un-P1-C16 Yes See Memory
modules.
Memory card 3 - DIMM 1 Un-P1-C16-C1 Yes
Memory card 3 - DIMM 2 Un-P1-C16-C2 Yes Note: The DIMM
fault and identify
LED is not visible
when the system
is in the service
position.
Memory card 3 - DIMM 3 Un-P1-C16-C3 Yes
Memory card 3 - DIMM 4 Un-P1-C16-C4 Yes
Memory card 3 - DIMM 5 Un-P1-C16-C7 Yes
Memory card 3 - DIMM 6 Un-P1-C16-C8 Yes
Memory card 3 - DIMM 7 Un-P1-C16-C9 Yes
Memory card 3 - DIMM 8 Un-P1-C16-C10 Yes
Memory card 4 Un-P1-C15 Yes See Memory
modules.
Memory card 4 - DIMM 1 Un-P1-C15-C1 Yes Note: The DIMM
fault and identify
LED is not visible
when the system
is in the service
position.
Memory card 4 - DIMM 2 Un-P1-C15-C2 Yes
Memory card 4 - DIMM 3 Un-P1-C15-C3 Yes
Memory card 4 - DIMM 4 Un-P1-C15-C4 Yes
Memory card 4 - DIMM 5 Un-P1-C15-C7 Yes
Memory card 4 - DIMM 6 Un-P1-C15-C8 Yes
Memory card 4 - DIMM 7 Un-P1-C15-C9 Yes
Memory card 4 - DIMM 8 Un-P1-C15-C10 Yes
Device physical locations
Tape drive (SAS) Un-P1-D1 No
Finding parts, locations, and addresses 25
