The following table provides location codes for parts that comprise the server.
Table 38. FRU locations and failing components
Failing item name Symbolic failing item
name
Physical location code Identify LED Failing item
removal and
replacement
procedures
System unit Un
Power supplies
Figure 51. Rear view of unit.
Figure 52. Front view of unit.
Finding parts, locations, and addresses 141
