Table 50. FRU locations and failing components (continued)

Failing item name Physical location code Identify LED Failing item removal

and replacement

procedures

Midplane Un-P1 Yes See Removing and

installing a

midplane.

Device physical locations

Disk drive 1 Un-P1-D1 Yes See Removing and

installing a disk

drive.

Disk drive 2 Un-P1-D2 Yes

Disk drive 3 Un-P1-D3 Yes

Disk drive 4 Un-P1-D4 Yes

Disk drive 5 Un-P1-D5 Yes

Disk drive 6 Un-P1-D6 Yes

Disk drive 7 Un-P1-D7 Yes

Disk drive 8 Un-P1-D8 Yes

Disk drive 9 Un-P1-D9 Yes

Disk drive 10 Un-P1-D10 Yes

Disk drive 11 Un-P1-D11 Yes

Disk drive 12 Un-P1-D12 Yes

Disk drive 13 Un-P1-D13 Yes

Disk drive 14 Un-P1-D14 Yes

Disk drive 15 Un-P1-D15 Yes

Disk drive 16 Un-P1-D16 Yes

Disk drive 17 Un-P1-D17 Yes

Disk drive 18 Un-P1-D18 Yes

Disk drive 19 Un-P1-D19 Yes

Disk drive 20 Un-P1-D20 Yes

Disk drive 21 Un-P1-D21 Yes

Disk drive 22 Un-P1-D22 Yes

Disk drive 23 Un-P1-D23 Yes

Disk drive 24 Un-P1-D24 Yes

Related reference:

5887 system parts

Indexed drawings show system part numbers.

5888 or EDR1 PCIe storage enclosure

The information provided in this topic defines specific sections of a location code string. Use this

information to understand the meaning of a location code.

Using location codes

Use the following table to link to a specific topic that you need additional information about when

reading your location code.

164 Finding parts, locations, and addresses
