GPU adapters
The server supports GPUs provided the appropriate riser card is installed (one or two riser cards
depending on the number of GPUs). For the NVIDIA Quadro K600, riser card 69Y5322 is used. For all
other GPUs, riser card 90Y5085 is used. The server provides up to 225W of external power to each GPU.
The following table lists the supported GPUs.
Table 19. GPU adapters
Part number Feature
code
Description Supported
with
E5-2600
Supported
with
E5-2600 v2
Maximum
supported
94Y5957 4798 NVIDIA Quadro 4000 Yes No 2
None* A26Q NVIDIA Quadro 6000 Yes No 2
None* A3WH NVIDIA Quadro K600 Yes Yes 4
None* A3WJ NVIDIA Quadro K2000 Yes Yes 2
None* A3YU NVIDIA Quadro K4000 Yes Yes 2
None* A3YW NVIDIA Quadro K5000 Yes Yes 2
00FP672 A3YV NVIDIA Quadro K6000 Yes Yes 2
None* A471 NVIDIA Tesla K20 (Actively Cooled) No Yes 1
00FP676 A5FG NVIDIA Tesla K40c No Yes 1
None* A470 NVIDIA Grid K2 (Actively Cooled) Yes Yes 2
* Available only via CTO or special bid.
The following configuration rules apply when selecting GPU adapters:
General requirements for all GPUs

Use the configurator tools to ensure the necessary cables, riser cards, air baffles, and other

prerequisites are selected
When 2 GPUs are selected (2, 3 or 4 GPUs in the case of the Quadro K600), the second

processor is required and will require a special heatsink
GPUs cannot be mixed

Further restrictions apply depending on the power supplies installed as described in the Power

supplies section.
Quadro 4000 requirements:
For models with E5-2600 processors. Models with E5-2600 v2 not supported.

Maximum 16x 32 GB LRDIMM and 32GB HyperCloud DIMM can be selected.

Maximum 512 GB system memory

Only drive backplanes 8x 2.5" HS HDD Kit (feature A1JX) or Plus 8x 2.5" HS HDD Assembly Kit

with Expander (feature A1JY) can be selected
Quadro 6000 requirements:

For models with E5-2600 processors. Models with E5-2600 v2 not supported.

Maximum 16x 32GB LRDIMM and 32GB HyperCloud DIMM can be selected.

Maximum 512GB system memory

Only drive backplanes 8x 2.5" HS HDD Kit (feature A1JX) or Plus 8x 2.5" HS HDD Assembly Kit

with Expander (feature A1JY) can be selected

IBM System x3650 M4 Specifications

General

Form Factor	2U Rack
Memory Slots	24 DIMM slots
Processor	Intel Xeon E5-2600 series
Memory	Up to 768GB DDR3
Storage	Up to 16 x 2.5-inch or 6 x 3.5" hot-swap SAS/SATA HDDs or SSDs
Power Supply	Redundant hot-swap 550W, 750W, or 900W
Network Interface	Quad-port 1 GbE
Chipset	Intel C600
RAID Support	RAID 0, 1, 10, 5, 6, 50, 60
Expansion Slots	Up to 6 PCIe slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
