Setting Up Your Computer
You are now ready to assemble and start your computer.
1
If you want to connect a printer to your computer, open the
connector cover. Connect one end of the printer cable to
the parallel connector and the other end to your printer.
Then power on the printer.
2
If you want to use the CD-ROM and the diskette drive at
the same time, you can attach the diskette drive to the
external-diskette-drive connector as follows:
Insert the diskette drive in the diskette-drive enclosure and
connect it firmly 1 . Connect the cable to the
external-diskette-drive connector 2 .
1
2
1
2
3
Connect the AC Adapter to the computer's power jack (at
the rear of the computer) in the order shown.
1
3
2
4
Open the liquid crystal display (LCD).
Pull the LCD latches 1 and open the LCD 2 . Then
position the LCD so that it is convenient for viewing.
1
1
2
5
Power on the computer.
a) Push and release the power switch 1 . The power
switch automatically snaps back to its original position.
b) Adjust the display's contrast or brightness 2 .
2
contrast ( )
or
brightness ( )
1
Copyright IBM Corporation 1998
3
