STEERING & DRIVE WHEEL GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 1113014 LOCK NUT, M14 1
2 1421428 FLAT WASHER, M14×
∮
28×2.0 1
3
8310602 STEERING WHEEL 1
8310699A CUSHION WITH ICE LOGO 1
4 8310608 BELLOWS, SHAFT, STEERING 1
5 1021825 BOLT, HEX HEAD, M8×25 8
6 1422821 LOCK WASHER, M8 6
7 1421816 FLAT WASHER, M18×
∮
16×1.6 4
8 8310609 BEARING, FLANGE 2
9 8310605 SHAFT, STEERING WHEEL 1
10 1654025 KEY, 4.75×4.75×25.4 2
11 8310604 U-JOINT 1
12 1534508 SET SCREW, M5 ×8 4
13 1123507 LOCK NUT, M5 3
14 1421510 FLAT WASHER, M5×
∮
10×1.0 3
15 6210131 CLAMP, NYLON 3
16 8310645 BRACKET, FLANGE BEARING 1
17 1021060 BOLT, HEX HEAD, M10×60 4
18 1422026 LOCK WASHER, M10 4
19 1421030 FLAT WASHER, M10×
∮
30×2.5 4
20 8310601 SUPPORT BRACKET, STEERING 1
21 1021820 BOLT, HEX HEAD, M8×20 4
22 1421824 FLAT WASHER, M14×
∮
24×2.0 8
23 8310640 ACCELERATOR/ BRAKE PEDAL 1
24 8310431 HALL SENSOR WITH CABLE 1
25 8310603 STEER-CONTROL ASSY. 1
26 8310650 DRIVE WHEEL, 24VDC 800W 1
27 8310611 PU TIRE, DRIVER WHEEL 1
28 8310612 ARMATURE BRUSH 4
29 8310613 BRUSHES CONNECTION BOX 2
30 8310618A ELECTRICALLY RELEASED BRAKE 1
