Icom IC-2800 Service Manual

D26 1790001670 S.DIODE RB706F-40T106
D27 1750000510 S.DIODE UM9401F
D28 1750000550 S.DIODE 1SS355 TE-17
D29 1160000060 S.DIODE DAN202U T107
D30 1790000860 S.DIODE MA133 (TX)
D31 1790001670 S.DIODE RB706F-40T106
D32 1160000060 S.DIODE DAN202U T107
D33 1790000620 S.DIODE MA77 (TX)
D35 1750000550 S.DIODE 1SS355 TE-17
D36 1790000450 S.DIODE MA862 (TX)
D37 1750000550 S.DIODE 1SS355 TE-17
D39 1750000510 S.DIODE UM9401F
D40 1730002340 S.ZENER MA8047-M (TX)
D41 1790001670 S.DIODE RB706F-40T106
D42 1730002340 S.ZENER MA8047-M (TX)
D43 1790001670 S.DIODE RB706F-40T106
D44 1790001520 S.ZENER MA8075-L (TX)
D45 1790000700 DIODE DSA3A1
D46 1730000520 ZENER RD20E B2
D47 1750000550 S.DIODE 1SS355 TE-17
D49 1750000550 S.DIODE 1SS355 TE-17 except [USA]
D50 1750000170 S.DIODE DA115 T107 [EUR], [ITA]
1160000060 S.DIODE DAN202U T107 [CSA]
D52 1750000550 S.DIODE 1SS355 TE-17 [USA], [SEA]
D53 1750000550 S.DIODE 1SS355 TE-17
except [ITA], [CSA]
D54 1750000550 S.DIODE 1SS355 TE-17
except [ITA], [CSA]
D55 1750000170 S.DIODE DA115 T107 [EUR], [ITA]
1160000060 S.DIODE DAN202U T107 [SEA]
D56 1750000550 S.DIODE 1SS355 TE-17 [ITA], [SEA]
D57 1750000550 S.DIODE 1SS355 TE-17 except [EUR]
D59 1710000600 DIODE 1SS254 [EUR]
D60 1710000600 DIODE 1SS254 except [USA]
D61 1790001000 S.ZENER MA8062-L (TX)
D62 1750000550 S.DIODE 1SS355 TE-17
D63 1730002280 S.ZENER MA8091-M (TX)
D64 1730002280 S.ZENER MA8091-M (TX)
D65 1750000550 S.DIODE 1SS355 TE-17
D66 1750000550 S.DIODE 1SS355 TE-17
D67 1790000660 S.DIODE MA728 (TX)
D68 1790001670 S.DIODE RB706F-40T106
D70 1790001010 S.ZENER MA8043-L (TX)
D71 1750000550 S.DIODE 1SS355 TE-17
D72 1710000870 S.DIODE HVU131TRF
D73 1750000550 S.DIODE 1SS355 TE-17
D74 1750000130 S.DIODE DA204U T107
D75 1750000130 S.DIODE DA204U T107
D76 1790000620 S.DIODE MA77 (TX)
D77 1790000620 S.DIODE MA77 (TX)
D78 1790000620 S.DIODE MA77 (TX)
D79 1750000550 S.DIODE 1SS355 TE-17
D80 1750000550 S.DIODE 1SS355 TE-17
FI1 2010002240 MONOLITHIC FL-288 (15.650 MHz)
FI2 2010002360 S.MONOLITHIC FL-300 (46.05 MHz)
FI3 2040001020 S.SAW EFCH445MWNP1 [USA], [CSA]
2040001000 S.SAW EFCH435MWNP1 other
FI4 2020001590 CERAMIC ALFY450F=K
FI5 2020001460 CERAMIC CFWS450HT [EUR], [ITA] only
FI6 2020001520 CERAMIC CFWS450F
X1 6050009820 XTAL CR-549 (15.2 MHz)
X2 6070000200 DISCRIMINATOR CDB450C24
X3 6070000200 DISCRIMINATOR CDB450C24
X4 6050010580 S.XTAL SMD-49 (10.000 MHz)
L1 6200002850 S.COIL NL 252018T-R82J
L2 6130002420 S.COIL LB-270
L3 6200002840 S.COIL NL 252018T-R22J
L4 6200002840 S.COIL NL 252018T-R22J
L5 6200005740 S.COIL ELJRE 47NG-F
L6 6200005690 S.COIL ELJRE 18NG-F
L7 6200006670 S.COIL ELJRE 68NG-F
L8 6200005710 S.COIL ELJRE 27NG-F
L9 6200006670 S.COIL ELJRE 68NG-F
L10 6200005740 S.COIL ELJRE 47NG-F
L11 6110001550 COIL LA-235
L12 6110001550 COIL LA-235
Q51 1530003230 S.TRANSISTOR 2SC5085-Y (TE85R)
Q52 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
[EUR], [ITA] only
Q53 1590000430 S.TRANSISTOR DTC144EUA T106
Q54 1560000840 S.FET 2SK1829 (TE85R)
[EUR], [ITA] only
Q55 1590001450 S.FET 2SJ144-GR (TE85R)
Q56 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q57 1560000530 S.FET 2SK880-GR (TE85R)
Q58 1590000720 S.TRANSISTOR DTA144EUA T106
[EUR], [ITA] only
Q59 1560000530 S.FET 2SK880-GR (TE85R)
Q60 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q61 1590000430 S.TRANSISTOR DTC144EUA T106
Q62 1590001450 S.FET 2SJ144-GR (TE85R)
Q63 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q64 1560000530 S.FET 2SK880-GR (TE85R)
Q65 1560000530 S.FET 2SK880-GR (TE85R)
Q66 1590000430 S.TRANSISTOR DTC144EUA T106
Q67 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q68 1530003230 S.TRANSISTOR 2SC5085-Y (TE85R)
Q69 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q70 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q71 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q72 1590000430 S.TRANSISTOR DTC144EUA T106
Q73 1590000430 S.TRANSISTOR DTC144EUA T106
Q74 1590002110 S.TRANSISTOR DTC143XU T107
Q75 1520000650 S.TRANSISTOR 2SB1201-S-TL
Q76 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q77 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q78 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q79 1510000510 S.TRANSISTOR 2SA1576A T106R
Q80 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q81 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q82 1590000430 S.TRANSISTOR DTC144EUA T106
Q83 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q84 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q85 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q86 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q87 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q88 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q89 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
[EUR], [ITA] only
Q90 1540000250 S.TRANSISTOR 2SD999-T2 CK
Q91 1590000720 S.TRANSISTOR DTA144EUA T106
Q92 1590000680 S.TRANSISTOR DTC114EUA T106
Q93 1590000430 S.TRANSISTOR DTC144EUA T106
Q95 1590000430 S.TRANSISTOR DTC144EUA T106
Q96 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q98 1590000660 S.TRANSISTOR DTC144TU T107
Q99 1530002490 S.TRANSISTOR 2SC3324-GR (TE85R)
Q100 1560000540 S.FET 2SK880-Y (TE85R)
Q101 1530002490 S.TRANSISTOR 2SC3324-GR (TE85R)
Q102 1560000540 S.FET 2SK880-Y (TE85R)
Q103 1590000430 S.TRANSISTOR DTC144EUA T106
[EUR], [ITA] only
D1 1750000550 S.DIODE 1SS355 TE-17
D2 1790000620 S.DIODE MA77 (TX)
D3 1720000370 S.VARICAP HVU350TRF
D4 1790000450 S.DIODE MA862 (TX)
D5 1750000370 S.DIODE DA221 TL
D6 1750000550 S.DIODE 1SS355 TE-17
D7 1790001670 S.DIODE RB706F-40T106
D8 1790001670 S.DIODE RB706F-40T106
D9 1750000510 S.DIODE UM9401F
D10 1160000060 S.DIODE DAN202U T107
D11 1720000370 S.VARICAP HVU350TRF
D12 1720000370 S.VARICAP HVU350TRF
D13 1720000370 S.VARICAP HVU350TRF
D14 1750000550 S.DIODE 1SS355 TE-17
D15 1720000370 S.VARICAP HVU350TRF
D16 1750000550 S.DIODE 1SS355 TE-17
D18 1750000510 S.DIODE UM9401F
D19 1750000550 S.DIODE 1SS355 TE-17
D20 1720000640 S.VARICAP 1SV284 (TPH3)
D21 1720000640 S.VARICAP 1SV284 (TPH3)
D22 1790000450 S.DIODE MA862 (TX)
D23 1790000620 S.DIODE MA77 (TX)
D24 1750000370 S.DIODE DA221 TL
D25 1790001670 S.DIODE RB706F-40T106
S.=Surface mount
6 - 5
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
