M GENERAL
• Frequency range :
*
1
Guaranteed 144.000 – 148.000 MHz only
*
2
Guaranteed 430.000 – 440.000 MHz only; *
3
Guaranteed 440.000 – 450.000 MHz only
• Mode : FM, AM (118.0 – 135.995; Rx only)
• Nomber of memory channel : 232 (incl. 6 pairs of scan edges, 10 log, 10 repeater and 2 call channels)
• Usable temperature range : –10˚C to +60˚C; +14˚F to +140˚F
• Frequency resolution : 5, 10, 12.5, 15, 20, 25, 30 and 50 kHz
• Frequency stability : ±10 ppm (–10˚C to +60˚C; +14˚F to +140˚F)
• Power supply requirement : 13.8 V DC ±15 % (negative ground)
• Current drain
(at 13.8 V DC) : Receive Standby (squelched) 1.2 A
Max. audio 1.5 A
Transmit at VHF 50 W/UHF 35 W 12.0 A/11.0 A
at 25 W/25 W (TPE version) 8.0 A
• Antenna connector : SO-239 (50 Ω)
• DATA connector : Mini DIN 6 pin
• External VIDEO input : PHONO [RCA (75 Ω)]
• Dimensions : Controller 140(W)
×70(H)×34(D) mm; 5
1
⁄2(W)×2
3
⁄4(H)×1
11
⁄32(D) inch
(projections not included) Main unit 140(W)×40(H)×165.8(D) mm; 5
1
⁄2(W)×1
9
⁄16(H)×6
17
⁄32(D) inch
• Weight : Controller 290 g; 10.2 oz
Main unit 1.15 kg; 2 lb 9 oz
M TRANSMITTER
• Output power : High VHF 50 W/UHF 35 W
Mid-H approx. 20 W
Mid-L approx. 10 W
Low approx. 5 W
• Modulation system : Variable reactance frequency
• Maximum frequency deviation : ±5.0/±2.5* kHz
*[EUR] and [ITA] versions only
• Spurious emissions : Less than –60 dB
• Microphone connector : 8-pin modular (600 Ω)
M RECEIVER
• Receive system : Double-conversion superheterodyne
• Intermediate frequency : VHF 1st IF 15.65 MHz 2nd IF 450 kHz
UHF 1st IF 46.05 MHz 2nd IF 450 kHz
• Sensitivity
(at 12 dB SINAD) : Less than 0.18 µV
• Squelch sensitivity
(threshold) : Less than 0.13 µV
• Selectivity
(wide/narrow) : More than 12/6* kHz at –6 dB
Less than 28/18* kHz at –60 dB
*[EUR] and [ITA] versions only
• Spurious and image rejection : More than 60 dB
• Intermodulation rejection ratio : More than 60 dB
• Audio output power
(at 13.8 V) : More than 2.4 W at 10% distortion with an 8Ω load
• External SP1 connector : 2-conductor 3.5(d) mm (
1
⁄8")/8 Ω
• External SP2 connector : 3-conductor 3.5(d) mm (
1
⁄8")/8 Ω
1 - 1
SECTION 1 SPECIFICATIONS
144 MHz band 440 MHz band
144.000 – 146.000 430.000 – 440.000
Rx: 136.000 – 174.000*
1
Rx: 400.000 – 530.000*
2
Tx: 144.000 – 148.000*
1
Tx: 430.000 – 440.000*
2
Rx: 118.000 – 174.000*
1
430.000 – 450.000*
3
Tx: 144.000 – 148.000*
1
Rx: 136.000 – 174.000*
1
430.000 – 440.000
Tx: 144.000 – 148.000*
1
Rx: 118.000 – 174.000*
1
Rx: 400.000 – 530.000*
2
Tx: 144.000 – 148.000*
1
Tx: 430.000 – 440.000*
2
All stated specifications are subject to change without notice or obligation.
Version
EUR
ITA
USA
SEA
CSA
