Icom IC-2800 Service Manual

3 - 1
SECTION 3 DISASSEMBLY INSTRUCTIONS
• Removing the MAIN unit
q Unscrew 1 screw,
A
, and remove the cover.
w Unplug J4 to separate the fan motor from the MAIN unit.
e Remove 2 main shield,
B, and TR-A clip,
C
in the direc-
tion of the arrow.
• Removing the CONTROL unit
q Unscrew 4 screws,
A
, and remove the cover.
w Unplug J5 to separate the speaker and front panel.
e Remove rear panel in the deirection of the arrow.
r Remove 6 knobs,
B
.
t Unscrew 5 screws,
C
, and remove the CONTROL unit in
the direction of the arrow.
y Unscrew 2 screws,
D
, when remove the LCD.
r Unsolder 3 points,
D
, and unscrew 11 nut,
E
.
t Remove the MAIN unit in the direction of the arrow.
A
B
B
C
Cover
J4
E
E
E
E
MAIN UNIT
Chassis
D
A
Rear panel
J5
Front panel
A
CONTROL
UNIT
D
D
B
B
LCD
C
C
