Page #27 background image
[MAIN UNIT][MAIN UNIT]
S.=Surface mount
D304 1790000620 S.DIODE MA77 (TX)
D305 1790000620 S.DIODE MA77 (TX)
D306 1790000620 S.DIODE MA77 (TX)
D401 1750000430 S.DIODE HSB88WSTR
D501 1160000070 S.DIODE DAN202K T146
D502 1790001250 S.DIODE MA2S111-(TX)
D503 1160000070 S.DIODE DAN202K T146
D601 1160000080 S.DIODE DAP202K T146
D602 1160000070 S.DIODE DAN202K T146
D603 1160000080 S.DIODE DAP202K T146
D604 1160000070 S.DIODE DAN202K T146
D605 1160000080 S.DIODE DAP202K T146
D606 1160000070 S.DIODE DAN202K T146
D607 1160000080 S.DIODE DAP202K T146
D608 1160000070 S.DIODE DAN202K T146
D701 1750000640 S.DIODE 1SV312 (TE85L)
D801 1750000640 S.DIODE 1SV312 (TE85L)
D802 1750000640 S.DIODE 1SV312 (TE85L)
D803 1790000620 S.DIODE MA77 (TX)
D804 1790000620 S.DIODE MA77 (TX)
D805 1790000620 S.DIODE MA77 (TX)
D806 1790000620 S.DIODE MA77 (TX)
D807 1790000620 S.DIODE MA77 (TX)
D808 1790000620 S.DIODE MA77 (TX)
D809 1790000620 S.DIODE MA77 (TX)
D810 1790000620 S.DIODE MA77 (TX)
D811 1790000620 S.DIODE MA77 (TX)
D812 1790000620 S.DIODE MA77 (TX)
D813 1790000620 S.DIODE MA77 (TX)
D814 1790000620 S.DIODE MA77 (TX)
D815 1790000620 S.DIODE MA77 (TX)
D816 1790000620 S.DIODE MA77 (TX)
D901 1790000620 S.DIODE MA77 (TX)
D902 1790000620 S.DIODE MA77 (TX)
D903 1790000620 S.DIODE MA77 (TX)
D904 1790000620 S.DIODE MA77 (TX)
D1301 1790000620 S.DIODE MA77 (TX)
D1302 1790000620 S.DIODE MA77 (TX)
D1501 1790001210 S.DIODE 1SS375-TL
D1503 1790001250 S.DIODE MA2S111-(TX)
D1510 1790001250 S.DIODE MA2S111-(TX)
D1631 1160000070 S.DIODE DAN202K T146
D1632 1790000620 S.DIODE MA77 (TX)
D1701 1730002450 S.ZENER MA8043-H (TX)
D1702 1730002450 S.ZENER MA8043-H (TX)
D1703 1790001240 S.DIODE MA2S728-(TX)
D1704 1160000080 S.DIODE DAP202K T146
D1705 1160000080 S.DIODE DAP202K T146
D1706 1790001250 S.DIODE MA2S111-(TX)
D1707 1790001250 S.DIODE MA2S111-(TX)
D1801 1790001210 S.DIODE 1SS375-TL
D1802 1790001250 S.DIODE MA2S111-(TX)
D1803 1790001210 S.DIODE 1SS375-TL
D1901 1790001210 S.DIODE 1SS375-TL
D2101 1790001250 S.DIODE MA2S111-(TX)
D2201 1750000370 S.DIODE DA221 TL
D2202 1750000370 S.DIODE DA221 TL
D2301 1790001250 S.DIODE MA2S111-(TX)
D2381 1790001210 S.DIODE 1SS375-TL
D2701 1160000080 S.DIODE DAP202K T146
D3001 1160000070 S.DIODE DAN202K T146
D3002 1160000070 S.DIODE DAN202K T146
D3502 1750000370 S.DIODE DA221 TL
D3503 1730002320 S.ZENER MA8051-M (TX)
D3701 1160000070 S.DIODE DAN202K T146
D4220 1790001240 S.DIODE MA2S728-(TX)
D4801 1790001250 S.DIODE MA2S111-(TX)
FI301 2010002470 XTAL FL-315 (64.45500 MHz)
FI611 2020000210 CERAMIC CFJ455K5 (FL-65)
FI1301 2020001330 CERAMIC CFWS455HT
L1 6200003260 S.COIL NL 322522T-101J
L2 6200003000 S.COIL NL 322522T-R22J-3
L100 6200004790 S.COIL MLF1608D R47K-T
L101 6200003000 S.COIL NL 322522T-R22J-3
L102 6200003010 S.COIL NL 322522T-R27J-3
L103 6200001850 S.COIL NL 322522T-5R6J
L104 6200003260 S.COIL NL 322522T-101J
L105 6140003210 S.COIL LR-358
L106 6150004270 COIL LS-483A (C-14924)
L151 6150004280 COIL LS-484B (C-14927)
L152 6200003260 S.COIL NL 322522T-101J
L153 6200003550 S.COIL MLF1608A 4R7K-T
L201 6200001830 S.COIL NL 322522T-100J
L202 6200003000 S.COIL NL 322522T-R22J-3
L301 6150004280 COIL LS-484B (C-14927)
L302 6150004280 COIL LS-484B (C-14927)
L303 6150004280 COIL LS-484B (C-14927)
L401 6140003210 S.COIL LR-358
L402 6140003530 COIL LR-395
L501 6150004090 COIL LS-469 (C-13969)
L701 6200003260 S.COIL NL 322522T-101J
L702 6200003260 S.COIL NL 322522T-101J
L703 6200003260 S.COIL NL 322522T-101J
L801 6200003260 S.COIL NL 322522T-101J
L802 6200009310 S.COIL ACL3225S-331M-T
L811 6200002960 S.COIL NL 322522T-4R7J-3
L812 6200003320 S.COIL NL 322522T-3R3J-3
L813 6200003260 S.COIL NL 322522T-101J
L814 6200003260 S.COIL NL 322522T-101J
L821 6200001850 S.COIL NL 322522T-5R6J
L822 6200003110 S.COIL NL 322522T-6R8J
L831 6200003260 S.COIL NL 322522T-101J
L832 6200003090 S.COIL NL 322522T-2R7J-3
L833 6200003100 S.COIL NL 322522T-3R9J-3
L835 6200002960 S.COIL NL 322522T-4R7J-3
L836 6200001850 S.COIL NL 322522T-5R6J
L841 6200003260 S.COIL NL 322522T-101J
L842 6200002990 S.COIL NL 322522T-2R2J-3
L843 6200002990 S.COIL NL 322522T-2R2J-3
L851 6200003260 S.COIL NL 322522T-101J
L852 6200003050 S.COIL NL 322522T-R82J-3
L853 6200003060 S.COIL NL 322522T-1R2J-3
L854 6200003080 S.COIL NL 322522T-1R8J-3
L855 6200003070 S.COIL NL 322522T-1R5J-3
L861 6200003260 S.COIL NL 322522T-101J
L862 6200003060 S.COIL NL 322522T-1R2J-3
L863 6200003330 S.COIL NL 322522T-1R0J-3
L864 6200003050 S.COIL NL 322522T-R82J-3
L865 6200003060 S.COIL NL 322522T-1R2J-3
L871 6200003260 S.COIL NL 322522T-101J
L872 6200003030 S.COIL NL 322522T-R47J-3
L873 6200002980 S.COIL NL 322522T-R56J-3
L874 6200003040 S.COIL NL 322522T-R68J-3
L875 6200003050 S.COIL NL 322522T-R82J-3
L881 6200003260 S.COIL NL 322522T-101J
L882 6200003250 S.COIL NL 322522T-R39J-3
L883 6200003250 S.COIL NL 322522T-R39J-3
L884 6200003030 S.COIL NL 322522T-R47J-3
L885 6200002980 S.COIL NL 322522T-R56J-3
L891 6200003260 S.COIL NL 322522T-101J
L892 6200003010 S.COIL NL 322522T-R27J-3
L893 6200003010 S.COIL NL 322522T-R27J-3
L894 6200003020 S.COIL NL 322522T-R33J-3
L895 6200003250 S.COIL NL 322522T-R39J-3
L901 6200003260 S.COIL NL 322522T-101J
L902 6180002960 S.COIL NL 322522T-R18J-3
L903 6200003010 S.COIL NL 322522T-R27J-3
L904 6200003020 S.COIL NL 322522T-R33J-3
L1101 6140003210 S.COIL LR-358
L1102 6140003620 COIL LR-403
L1103 6150004270 COIL LS-483A (C-14924)
L1104 6200003260 S.COIL NL 322522T-101J
L1201 6150004280 COIL LS-484B (C-14927)
L1202 6150004280 COIL LS-484B (C-14927)
L1301 6150004080 COIL LS-468 (C-13958)
L1302 6150004080 COIL LS-468 (C-13958)
L1303 6150004080 COIL LS-468 (C-13958)
L1304 6200009310 S.COIL ACL3225S-331M-T
L1401 6140000640 COIL LR-86
L1402 6140003550 COIL LR-397
L1501 6150002291 COIL LS-450
L1502 6150002291 COIL LS-450
L1503 6200009310 S.COIL ACL3225S-331M-T
L1601 6150002291 COIL LS-450
L1611 6150002291 COIL LS-450
L1621 6150002291 COIL LS-450
L2001 6200003260 S.COIL NL 322522T-101J
L2301 6200003260 S.COIL NL 322522T-101J
L2901 6170000140 COIL LW-15
L3501 6180000960 COIL LAL 03NA 102K
6 - 4
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
