Icom IC-718 Service Manual

[PA UNIT][PLL UNIT]
S.=Surface mount
C224 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C225 4030006940 S.CERAMIC C1608 CH 1H 030C-T-A
C226 4030006940 S.CERAMIC C1608 CH 1H 030C-T-A
C227 4030007100 S.CERAMIC C1608 CH 1H 560J-T-A
J1 6510018960 S.CONNECTOR B2B-PH-SM3-TB
J3 6510022000 S.CONNECTOR 16FMN-BMTTR-TBT
J4 6510018960 S.CONNECTOR B2B-PH-SM3-TB
W1 7030003860 S.JUMPER ERJ3GE JPW V
W5 7030003860 S.JUMPER ERJ3GE JPW V
W7 7030003860 S.JUMPER ERJ3GE JPW V
W9 7030003860 S.JUMPER ERJ3GE JPW V
W10 7030003860 S.JUMPER ERJ3GE JPW V
W92 7030003860 S.JUMPER ERJ3GE JPW V
W170 7030003860 S.JUMPER ERJ3GE JPW V
WS1 8970023621 E.OTHER
SX2242 0.8D COAXIAL TUBE (2)/PL
WS2 8970023630 E.OTHER SX2242 ICOM SHIELD (1)/PL
EP1 0910052025 PCB B 5379E
Q1 1530000790 TRANSISTOR 2SC1971
Q2 1530000190 TRANSISTOR 2SC3133
Q3 1530000190 TRANSISTOR 2SC3133
Q4 1530000200 TRANSISTOR 2SC2904
Q5 1530000200 TRANSISTOR 2SC2904
Q6 1540000500 TRANSISTOR 2SD1585K
Q7 1590001150 S.TRANSISTOR UN9211 (TX)
D1 1790000710 VARISTOR MA29B
D2 1790000710 VARISTOR MA29B
D3 1790000710 VARISTOR MA29B
D4 1790000700 DIODE DSA3A1
D5 1790000700 DIODE DSA3A1
D6 1160000140 S.DIODE DAP222 TL
D7 1730000480 S.ZENER RD10M-T2B3
L1 6140002350 COIL LR-274 (RIB4X7X5 3A6)
L2 6140002980 COIL LR-143
L3 6140003600 COIL LR-401
L4 6140003590 COIL LR-400
L5 6140003220 COIL LR-359 (SK-10M-15YY(120)
L6 6910000670 COIL BL01RN1-A62-001
L7 6910000670 COIL BL01RN1-A62-001
L8 6910000670 COIL BL01RN1-A62-001
L14 6180001230 COIL LAL 04NA 8R2K
L19 6200003840 S.COIL MLF2012D R22K-T
L20 6910000670 COIL BL01RN1-A62-001
L21 6910000670 COIL BL01RN1-A62-001
L22 2040000490 COIL EXC-ELDR25C
L23 2040000490 COIL EXC-ELDR25C
L24 6200003240 S.COIL NL 322522T-221J
L25 6200003240 S.COIL NL 322522T-221J
L26 6200008820 S.COIL HF70ACC 635050-T
L27 6200008820 S.COIL HF70ACC 635050-T
L28 6140003440 COIL LR-386 [EUR], [ITA], [FRA], [ESP]
L29 6140003440 COIL LR-386 [EUR], [ITA], [FRA], [ESP]
L30 2040000490 COIL EXC-ELDR25C
L31 2040000490 COIL EXC-ELDR25C
R1 7030003310 S.RESISTOR ERJ3GEYJ 820 V (82 Ω)
R2 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R3 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R4 7030006210 S.RESISTOR ERJ12YJ4R7U (4.7 Ω)
R5 7030006250 S.RESISTOR ERJ12YJ271U (270 Ω)
R6 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R7 7030000220 S.RESISTOR MCR10EZHJ 47 Ω (470)
R8 7030000220 S.RESISTOR MCR10EZHJ 47 Ω (470)
R9 7030009230 S.RESISTOR ERJ1WYJ121U (120 Ω)
R10 7030009230 S.RESISTOR ERJ1WYJ121U (120 Ω)
R11 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R12 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R13 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R15 7030008000 S.RESISTOR ERJ1WYJ3R3U (3.3 Ω)
R16 7030008000 S.RESISTOR ERJ1WYJ3R3U (3.3 Ω)
R17 7030006060 S.RESISTOR ERJ12YJ100U (10 Ω)
R18 7030006060 S.RESISTOR ERJ12YJ100U (10 Ω)
R20 7030006070 S.RESISTOR ERJ12YJ101U (100 Ω)
R21 7310003750 TRIMMER EVN-2ACA00 B52 (501)
R22 7030006130 S.RESISTOR ERJ1WYJ100U (10 Ω)
R23 7030010070 S.RESISTOR ERJ12YJ681U (680 Ω)
R24 7310003240 TRIMMER EVN-2ACA00 B23 (202)
R25 7100000640 RESISTOR 5 SI 0.012 Ω (J)
R26 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R27 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R28 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R29 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R30 7510000130 THERMISTOR ERT-D2FHL 333S
R31 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R32 7030006130 S.RESISTOR ERJ1WYJ100U (10 Ω)
R33 7030006130 S.RESISTOR ERJ1WYJ100U (10 Ω)
R34 7030008000 S.RESISTOR ERJ1WYJ3R3U (3.3 Ω)
R35 7030008000 S.RESISTOR ERJ1WYJ3R3U (3.3 Ω)
R36 7030008000 S.RESISTOR ERJ1WYJ3R3U (3.3 Ω)
R37 7030008000 S.RESISTOR ERJ1WYJ3R3U (3.3 Ω)
C1 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C2 4030004720 S.CERAMIC C2012 JB 1H 102K-T-A
C3 4030004740 S.CERAMIC C2012 JB 1H 472K-T-A
C4 4030005110 S.CERAMIC C2012 JB 1E 473K-T-A
C5 4030012490 S.CERAMIC GRM42-6 SL 472J 100PT
C6 4030012490 S.CERAMIC GRM42-6 SL 472J 100PT
C8 4030011260 S.CERAMIC GRM42-6 W5R 102K 500PT
C11 4030011260 S.CERAMIC GRM42-6 W5R 102K 500PT
C13 4010005870 CERAMIC HM95SJ SL 221J 500V
C14 4010005870 CERAMIC HM95SJ SL 221J 500V
C15 4320000650 DIP MICA KD20C 102J5
C16 4320000780 DIP MICA KD19C 821J5
C17 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C19 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C20 4510006230 S.ELECTROLYTIC ECEV1EA470UP
C21 4030005110 S.CERAMIC C2012 JB 1E 473K-T-A
C22 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C23 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C24 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C25 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C26 4510006230 S.ELECTROLYTIC ECEV1EA470UP
C27 4510004600 ELECTROLYTIC 16 MV 1000 HC
C28 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C29 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C30 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C31 4030005110 S.CERAMIC C2012 JB 1E 473K-T-A
C32 4510004600 ELECTROLYTIC 16 MV 1000 HC
C33 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C34 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C35 4030005140 S.CERAMIC C3216 JB 1E 104K-T-A
[USA/-1], [OTH], [KOR]
C38 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C39 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C42 4510004600 ELECTROLYTIC 16 MV 1000 HC
C45 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C46 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C47 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C48 4030005140 S.CERAMIC C3216 JB 1E 104K-T-A
C49 4030007120 S.CERAMIC C1608 CH 1H 820J-T-A
C50 4030007120 S.CERAMIC C1608 CH 1H 820J-T-A
C51 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C52 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C53 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C54 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C55 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C56 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C57 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C59 4510006650 S.ELECTROLYTIC ECEV1EA100SR
[EUR], [ITA], [FRA], [ESP]
C60 4030004740 S.CERAMIC C2012 JB 1H 472K-T-A
[EUR], [ITA], [FRA], [ESP]
6 - 12
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[PA UNIT]
REF ORDER
DESCRIPTION
NO. NO.
