39
5
BATTERY CHARGING
D Using the BC-197 to rapid charge the BP-264 or
BP-265
The BC-197 rapidly charges up to six battery packs.
Charging time for the BP-264: Approximately 2 hours.
Charging time for the BP-265: Approximately 2.5 hours.
The following additional item is required:
• A power adapter (not supplied with some versions) or the DC
power cable (OPC-656)
(A power adapter is
not supplied with
some versions.)
Power adapter
(Connect to a DC power supply:
12 to 16 V/at least 7 A)
Red line : + Black line : _
Transceiver
Battery pack
Tu rn OFF the power
Status indicator
(each indicator independently functions)
Charger adapters* are
installed in each slot.
The shape of charger adapter depends
on the version of the BC-197.
*
DC power cable (OPC-656)
To Next Page
