Icom IC-F3GS User Manual

2
ACCESSORIES
PANEL DESCRIPTION
1
3 4
‘‘
Accessory attachment
D Supplied accessories
The transceiver comes supplied with the following accessories.
q Flexible antenna
w Belt clip
e 2251 OPT sheet
(See p. 26)
D Antenna
The antenna screws onto the transceiver as
illustrated right.
Keep the jack cover attached when jacks are
not in use to avoid bad contacts.
D Belt clip
Attach the belt clip to the transceiver as illustrated below.
q
w
e
‘‘
Function display
q TRANSMIT INDICATOR
Appears during PTT on.
w BUSY INDICATOR
Appears while receiving a signal or when the squelch is open.
e LOW POWER INDICATOR (p. 12)
Appears when low output power is selected.
r SCRAMBLER INDICATOR
Appears while the scrambler function is operating.
t KEY LOCK INDICATOR (p. 12)
Appears during key lock function ON.
y BELL INDICATION
Appears or blinks when the optional 2/5Tone call is received.
u AUDIBLE INDICATOR
Appears when monitor function is turned ON. (CTCSS and DTCS
mutes are released.)
i LOW BATTERY INDICATOR [ ]
-When appears, battery
capacity is low and transmitting is impossible.
- When flashes, battery capacity is nearly exhausted.
o ALPHANUMERIC INDICATOR
o
qw e r tyu i
To attach the belt-clip
To release the belt-clip
