5 - 4
L21
DETECTOR OUTPUT VOLTAGE
adjustment
QUAD
DETECTOR OUTPUT VOLTAGE
check point
V
2ND VCO LOCK VOLTAGE
check point
LV1
1ST VCO LOCK VOLTAGE
check point
F
REFERENCE FREQUENCY
check point
L63
1ST VCO LOCK VOLTAGE
adjustment
Bottom view
