Icom IC-R5 Service Manual

1 - 1
SECTION 1 SPECIFICATIONS
M GENERAL
• Frequency range :
• Mode : FM, WFM, AM
• No. of memory channel : 1250 channel
(incl. scan edge and auto
memory right ch.)
• Frequency stability : ±6 ppm max.
(–10˚C to +60˚)
• Tuning steps : 5, 6.25, 10, 12.5, 15, 20,
25, 30, 50, and 100 kHz
• Anntena Impedance : 50 Ω
• Power supply requirement : 2
× AA(R6) Ni-Cd, alkaline
cells or external power
supply (BC-136, CP-17)
• Polarity : Negative ground
• Frequency resolution : 5 kHz, 6.25 kHz
• Current drain (at 3.0 V) :
Rated audio 170 mA typical
Standby 100 mA typical
Power saved 41 mA typical
(Power save ratio is 1 : 4)
• Usable temperature range : –10˚C to +60˚C
( –14˚F to +140˚F)
• Dimensions :
58(W) × 86(H) × 27(D) mm;
(projections not included) 2
9
⁄
32
(W)
×
3
3
⁄
8
(H)
×
1
1
⁄
16
(D) in
• Weight (with antenna and battely) : 185 (g); 6.5 (oz)
• External SP connector : 3-conductor 3.5(d) mm
(
1
⁄8”) / 8Ω
M RECEIVER
• Receiver system : Tripple super heterodyne
• Intermediate frequency : 1st 266.7 MHz
2nd 19.65 MHz
3rd 450 kHz
• Sensitivity* :
(except spurious points)
*
FM and WFM are measured at 12 dB SINAD; AM is measured
at 10 dB S/N.
• Squelch Sensitivity :
• Selectivity :
AM / FM more than 15 kHz / –6 dB
less than 30 kHz / –60 dB
WFM more than 150 kHz / –6 dB
• Audio output power : 100 mW typical at 10 %
distortion with an 8 Ω load
All stated specifications are subject to change without notice or obligation.
Version
EUR, U.K.,
ITA, ESP, CAN
EXP-01, EXP-02
U.S.A.
FRA
Receive Frequencies (MHz)
0.495 – 1309.995
0.150–823.995, 849.000–868.995,
894.000–1309.995
0.150–29.995, 50.200–51.200,
87.500–108.000, 144.000–146.000
430.000–440.000, 1240.000–1300.000
Frequency (MHz)
0.495 – 1.625
1.625 – 4.995
5.000 – 29.995
30.000 – 75.995
76.000 – 108.000
108.000 – 117.995
118.000 – 136.000
136.000 – 175.000
175.000 – 221.995
222.000 – 246.995
247.000 – 329.995
330.000 – 469.995
470.000 – 770.000
770.000 – 999.995
1000.000 – 1309.995
FM
—
0.32 µV
0.2 µV
0.18 µV
0.2 µV
0.18 µV
0.28 µV
0.35 µV
WFM
—
0.89 µV
—
0.71 µV
—
1.0 µV
—
AM
1.3 µV
0.71 µV
—
0.56 µV
—
0.56 µV
0.61 µV
—
Frequency (MHz)
0.495 – 1.625
1.625 – 5.0
5.0 – 30.0
30.0 – 76.0
76.0 – 108.0
108.0 – 118.0
118.0 – 136.0
136.0 – 175.0
175.0 – 222.0
222.0 – 247.0
247.0 – 330.0
330.0 – 470.0
470.0 – 770.0
770.0 – 833.0
833.0 – 1309.995
FM
—
0.56 µV
0.4 µV
0.56 µV
0.79 µV
WFM
—
5.6 µV
—
5.6 µV
—
5.6 µV
—
AM
2.5 µV
1.8 µV
—
1.8 µV
—
1.8 µV
—
