S.=Surface mount
R1 7210000140 VARIABLE RK1631110D9DA (10KA)
R2 7210000690 VARIABLE RK1631110D9CA (10KB)
S1 2260001260 SWITCH SW-118 (SDDFA3)
SP1 2510000040 SPEAKER C065K12I0810
W1 8900008620 CABLE OPC-844
WS1 8600033720 M.OTHER FX1623 P02FR
WS2 8600033730 M.OTHER FX1623 P03FR
C1 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C2 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C3 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
J1 6510004820 CONNECTOR FM14RS-7SS
J2 6510003410 CONNECTOR B05B-EH-S
WS1 8600036390 M.OTHER FX2169 P01*P02MI
EP1 0910050531 PCB B 5201A
J1 6510003430 CONNECTOR B07B-EH-S
J2 6510003390 CONNECTOR B03B-EH-S
S1 2230000380 SWITCH SPUE44067A
W8 6910001030 JUMPER IPS-1041-4
WS1 8600036400 M.OTHER FX2169 P01*P02SW
EP1 0910051070 PCB B 5251
R1 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R2 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R3 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R4 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R5 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R6 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R7 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
J1 6510003440 CONNECTOR B08B-EH-S
DS1 5040002450 LED TLG208
DS2 5040002450 LED TLG208
DS3 5040002460 LED TLR208
DS4 5040000650 LED TLY205
DS5 5040000640 LED TLR205
DS6 5040000650 LED TLY205
DS7 5040001360 LED TLG205
WS1 8600036410 M.OTHER FX2169 P01*P02LE
EP1 0910050541 PCB B 5202A
IC1 1140001480 S.IC µPD78213GC-AB8
IC2 1130004080 S.IC µPD71055GB-3B4
IC4 1130004712 IC NM27C256Q150
IC5 1130004790 S.IC TC74HC374AF
IC6 1130004011 S.IC TC74HC138AF
IC7 1130004921 S.IC TC74HC04AF(TP1)
IC8 1110001501 S.IC S-80845ALUP-EA9-T2
IC9 1180000970 S.IC AN78L05M-(E1)
IC10 1130002390 S.IC µPD4049UBG
IC11 1130002390 S.IC µPD4049UBG
IC12 1110000960 S.IC NJM4558M-T1
IC13 1110000960 S.IC NJM4558M-T1
IC14 1110002420 S.IC NJM2073M-T1
IC15 1110003090 IC LA4425A
IC16 1110000960 S.IC NJM4558M-T1
IC17 1110000960 S.IC NJM4558M-T1
IC18 1110000960 S.IC NJM4558M-T1
IC19 1110000960 S.IC NJM4558M-T1
IC20 1130005640 S.IC TC4W53F (TE12L)
IC21 1110001590 S.IC TA75393F (TP1)
Q1 1590000680 S.TRANSISTOR DTC114EUA T106
Q3 1590000680 S.TRANSISTOR DTC114EUA T106
Q4 1590000680 S.TRANSISTOR DTC114EUA T106
Q5 1590001600 S.TRANSISTOR UMD3 TL
Q6 1590000680 S.TRANSISTOR DTC114EUA T106
Q7 1590000680 S.TRANSISTOR DTC114EUA T106
Q8 1590000680 S.TRANSISTOR DTC114EUA T106
Q9 1590000680 S.TRANSISTOR DTC114EUA T106
Q10 1590000680 S.TRANSISTOR DTC114EUA T106
Q11 1590001450 S.FET 2SJ144-GR (TE85R)
Q12 1590000680 S.TRANSISTOR DTC114EUA T106
Q13 1590001450 S.FET 2SJ144-GR (TE85R)
Q14 1590000680 S.TRANSISTOR DTC114EUA T106
D1 1790001200 S.DIODE MA6S121(TX)
D2 1790001200 S.DIODE MA6S121(TX)
D3 1790001200 S.DIODE MA6S121(TX)
4 - 1
REF ORDER
DESCRIPTION
NO. NO.
[FRONT UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[LED UNIT]
SECTION 4 PARTS LIST
REF ORDER
DESCRIPTION
NO. NO.
[MIC UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[SWITCH UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
