InFocus X2 User Manual

18
VGA connection
If your video device has a 15-pin VGA output, plug one end of the included
computer cable into the VGA connector on your video source. This connec-
tor may be labeled “To Monitor” on the video source. Plug the M1 computer
end of the cable into the Computer In connector on the projector. Do not
plug the USB end of this cable into the video device.
Use the A/V cable’s red and white audio connectors as described on the
previous page (the yellow connectors on the A/V cable are not used).
M1 to Component adapter
To connect a progressive scan DVD or HD source, use an M1 to Component
adapter (available as an optional accessory). Connect one end of a compo-
nent cable (not provided) into the adapter. Connect the M1 end of the
adapter into the Computer 1 connector on the projector.
Connect the power cord to the Powe r connector on the side of the projector
and to your electrical outlet.
NOTE: Always use the power cord that shipped with the projector.
connect computer and
A/V cables
connect power cable
X2_usrguide_One_Year.fm Page 18 Wednesday, April 21, 2004 9:34 AM

InFocus X2 Specifications

General

Number of colors	16.78 million colors
Native aspect ratio	-
Projection distance	- m
Vertical scan range	50 - 85 Hz
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	- \
Projector native resolution	SVGA (800x600)
Focal length range	- mm
Number of built-in speakers	1
Lamp type	SHP
Lamp power	200 W
Service life of light source	3000 h
Full HD	No
Analog signal format system	NTSC, PAL
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	- dB
Placement	Desktop
Product type	Standard throw projector
Product color	Gray
Power consumption (standby)	- W
Harmonized System (HS) code	85286200

Weight and Dimensions

Weight	3100 g
