No. Interface Name Function
1 Signal indicators
Corresponding to various output signals. ON: output active OFF: output
inactive
2
Local expansion module
back-end interface
Connect back-end module, not supporting hot plugging
3 User input terminals 4groups output with 8 channels in each group
4
Local expansion module
front-end interface
Connect front-end module, not supporting hot plugging
■ General Specications
Item GL10-0016ETN
Output channel 32
Output connecting mode 40-pin high-density terminal
Output type Transistor, low-side output
Power supply voltage 24 VDC (–15% to +20%)
Output voltage class 12 V to 24 V (-15% to +20%)
Internal 5 V power consumption 170 mA (typical value)
Maximum leakage current when the module is
turned OFF
Less than 0.5 mA
Response time when the module is turned ON Less than 0.5 ms (for hardware)
OFF response time Less than 0.5 ms (for hardware)
Maximum
load
Resistive load 0.5 A/point; 2 A/common terminal
Inductive load 12 W/24 VDC (total)
Lamp load 2 W/24 VDC (total)
Isolation method Opto-couplers isolation
Output action display Output indicator ON when opto-coupler driving is applied
Short circuit-proof output Yes
4. Mechanical Design Reference
■ Mounting Dimensions
90.00
95.00
32.0
90.0
95.0
36 35
2 1
CN1
Figure 3 Mounting dimensions (in mm)
5. Electrical Design Reference
■ Cable Preparing Procedures
◆ Strip back the wire outer coating by 6 mm. Pass the cable through the tube of proper wire size.
◆ Insert the exposed end into the hole of the cable lug, and then crimp it with recommended crimping tool.
◆ Put the cable lug onto the terminal and tighten the screw with a screwdriver. The maximum tightening torque
is 0.45 N.m.
NN
1BTTUISPVHIUIFUVCFPG
QSPQFSXJSFTJ[F
$SJNQJUXJUIBDSJNQJOHUPPM
Figure 4 Diagram of cable preparing
■ Terminal Arrangement
The GL10-0032ETN module supports 32-channel digital output and uses a 40-pin high-density terminal as a user
terminal. The following gure shows the interface diagram:
Figure 5 Terminal denition of the GL10-0032ETN digital output module
The following gure shows the internal circuit and external wiring of the interface. Please nish corresponding
wiring according to actual requirements:
◆ +24V_0 and COM0 supply 24V power for the 1st output group; +24V_1 and COM1 supply 24V power for the 2nd
output group.
5FSNJOBM
/P
#
4JHOBM/BNF
&YUFSOBM
8JSJOH
"
7@
:
$0.
0VUQVU
0VUQVU
0VUQVU
0VUQVU
0VUQVU
0VUQVU
0VUQVU
0VUQVU
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
7/FHBUJWF71PTJUJWF
7@
$0.
7%$
7@
$0.
7@
7%$
7%$
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
7%$
4JHOBM/BNF
&YUFSOBM
8JSJOH
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
-PBE
$0.
5 64
■ Wiring Precautions
1） After the I/O terminal block is installed to the CN5, x it at 0.2 to 0.25 Nm torque, as shown in the gure
below：
2） Do not bundle the terminal connection cables together with power cables (high voltage, large current) which
produce strong interference signals. Separate it from other cables and avoid cabling in parallel.
