What does user-defined fault 2 mean for Inovance MD380T11GB DC Drives?
If your Inovance DC Drive reports a 'User-defined fault 2', it means the user-defined fault 2 signal is being input via DI or virtual I/O. To resolve this, reset the operation.
Why does Inovance DC Drives have overcurrent during acceleration?
When an Inovance DC drive experiences overcurrent during acceleration, it may be due to a grounded or short-circuited output circuit, failure to perform motor auto-tuning, an excessively short acceleration time, an inappropriate manual torque boost or V/F curve, low voltage, starting a rotating motor, a sudden load during acceleration, or an undersized AC drive. To address this, eliminate external faults, perform motor auto-tuning, increase the acceleration time, adjust the manual torque boost or V/F curve, correct the voltage, use rotational speed tracking restart or wait for the motor to stop before starting, remove the added load, or select an AC drive with a higher power class.
What to do if Inovance MD380T11GB show overcurrent at constant speed?
If you observe overcurrent at constant speed in Inovance DC Drives, it could be caused by a grounded or short-circuited output circuit, failure to perform motor auto-tuning, low voltage, a sudden load during operation, or an AC drive model with insufficient power. To fix this, eliminate any external faults, perform motor auto-tuning, ensure the voltage is within the normal range, remove any added loads, or choose an AC drive with a higher power class.
Why does Inovance MD380T11GB DC Drives have overvoltage during deceleration?
If overvoltage occurs during deceleration in Inovance DC Drives, it could be due to high input voltage, an external force driving the motor, a deceleration time that is too short, or the absence of a braking unit and resistor. To solve this, adjust the voltage to the normal range, eliminate the external force or install a braking resistor, increase the deceleration time, or install the braking unit and braking resistor.
What does accumulative power-on time reached mean for Inovance DC Drives?
If your Inovance DC Drive indicates that the 'Accumulative power-on time reached', it signifies that the preset power-on time has been reached. Clear the record by using the parameter initialization function.
What causes initial position fault in Inovance MD380T11GB DC Drives?
If your Inovance DC Drive shows an initial position fault, it means the motor parameters are not set based on the actual situation. Check that the motor parameters are set correctly and verify that the setting of rated current is not too small.
What does AC drive hardware fault mean in Inovance MD380T11GB DC Drives?
If your Inovance DC Drive displays an 'AC drive hardware fault', it indicates either an overvoltage or overcurrent condition. Address the issue based on the specific overvoltage or overcurrent troubleshooting steps.
What causes pulse-by-pulse current limit fault in Inovance DC Drives?
If your Inovance DC Drive is experiencing a pulse-by-pulse current limit fault, it could be due to an excessively heavy load, a locked rotor on the motor, or an AC drive model with insufficient power. To fix this, reduce the load and check the motor and mechanical condition, or select an AC drive of higher power class.
What causes EEPROM read- write fault in Inovance MD380T11GB DC Drives?
If your Inovance DC Drive displays an EEPROM read-write fault, it indicates that the EEPROM chip is damaged. Replace the main control board to resolve this.
What causes power input phase loss in Inovance MD380T11GB?
If your Inovance DC Drives show power input phase loss, it could be due to an abnormal three-phase power input, a faulty drive board, a faulty lightening board, or a faulty main control board. To address this, eliminate external faults or contact Inovance or their agent.
