Intel DH55HC Product Guide

Installing and Replacing Desktop Board Components
33
4. Remove the protective socket cover from the socket by placing your thumb against
the front edge of the cover and resting your index finger on the rear grip
(Figure 8, A). Lift the front edge of the socket to disengage the cover from the
socket and lift the
cover up and
away from the socket (Figure 8, B). Do not touch
the socket contacts.
NOTE
Do not discard the socket cover; save it for possible future use. Always replace
the socket cover if you remove the processor from the socket.
Figure 8. Remove the Socket Cover

Intel DH55HC Specifications

General

Form Factor	MicroATX
Socket	LGA 1156
Memory Type	DDR3
Memory Slots	4
Max Memory	16 GB
PCI Express x16	1
PCIe 2.0 x1 Slots	2
PCI Slots	1
VGA	1
DVI-D	1
HDMI	1
Audio Codec	Realtek ALC888S
Chipset	Intel H55 Express
Memory Standard	DDR3 1333/1066
SATA Ports	6
USB Ports	12 x USB 2.0
Audio	Realtek ALC888S
LAN	Intel 82578DC Gigabit Ethernet Controller
