Interlogix GS960 User Manual

P/N 422-6367-ML • REV E • ISS 03DEC18 5 / 14
Understanding the LED when the detector
is in operation
The LED can have the following states in operation:
• Flashes 1 to 3 times when powered ON: Indication of
range setting after power-on
• Off: Normal state, no alarms
• Permanently on: Intrusion detected – if detector in Latch
mode
• Permanently on with 2 dips per 3 s: Low supply voltage or
self-test failure
Understanding the LED when testing the
detector with GS960-TR tester
The LED can have the following states during the test:
• Flickers: In test mode
• Flickers and blinks: In calibration mode
• Flashes 1.5 s: Confirms received signal
• Blinks slowly 1 time each 2.5 s after calibration: Set range
setting to Zone 1 (4 to 9 m)
• Blinks slowly 2 times each 2.5 s after calibration: Set
range setting to Zone 2 (2 to 4 m)
• Blinks slowly 3 times each 2.5 s after calibration: Set
range setting to Zone 3 (1 to 2 m)
Troubleshooting
Detector does not respond:
• Check the supply voltage and polarity
LED permanently on:
• Switch off the detector for a short period
• Check if LED is in latching mode (DIP 1 ON)
LED permanently on with 2 dips per 3 s:
• Check supply voltage – it should be higher than 7 V
No alarm:
• Check the INTRUSION and FAULT relay wiring
• Check the alarm loop wiring
Specifications
Type (thickness) of protected glass:
Minimum
Float (4 mm)
Maximum
Laminated P4 (4 + 4 mm)
Size of protected glass
40 × 40 cm min.
Max range
9 m radius/165°
Range setting
Zone 1: 4 to 9 m
Zone 2: 2 to 4 m
Zone 3: 1 to 2 m
Supply voltage
7 to 30 V DC
Max. voltage ripple
2 Vp-p at 12 V, 4 Vp-p at 24 V
Voltage monitoring
Fault signalled at < 7 V
Current consumption, max.
8.9 mA at 12 V, 5.9 mA at 24 V
D/N signal levels
DAY: D/N open or < 2.5 V,
NIGHT: D/N > 2.5 V
INTRUSION output
Relay
INTRUSION relay contact rating
50 mA, 50 V DC / peak AC,
Rs ≤ 30 Ω
TAMPER contact rating
50 mA / 50 V DC / peak AC
Intrusion/fault indication
LED
Environmental class EN 50130-
5:2011, VdS 2110
Class I
Operating temp. range
+5 to 40°C
Operating humidity range
Max. 93% RH
Housing material
Plastic ABS, white
Dimensions (W x H x D)
68 x 109 x 40 mm
Security grade
EN 50131-2-7-1:2012/A1:2013,
Grade 2; VdS 2332, class B
Approvals
VdS: G118504
Accessory
GS960-RB plug-in EOL resistor
board
Regulatory information
Manufacturer
PLACED ON THE MARKET BY:
UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092,
USA
AUTHORIZED EU REPRESENTATIVE:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Product warnings
and disclaimers
THESE PRODUCTS ARE INTENDED FOR
SALE TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. UTC FIRE & SECURITY
CANNOT PROVIDE ANY ASSURANCE THAT
ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY “AUTHORIZED
DEALER” OR “AUTHORIZED RESELLER”, IS
PROPERLY TRAINED OR EXPERIENCED TO
CORRECTLY INSTALL FIRE AND SECURITY
RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/ or scan the QR code.
Certification
European Union
directives
UTC Fire & Security hereby declares that this
device is in compliance with the applicable
requirements and provisions of the Directive
2014/30/EU. For more information see
www.utcfireandsecurity.com or
www.interlogix.com.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
www.utcfssecurityproducts.eu/recycle/
Contact information
www.utcfireandsecurity.com or www.interlogix.com
For customer support, see www.utcfssecurityproducts.eu
