PARTS REFERENCE
Before assembling your product, please take a few minutes to check the
contents and become familiar with all the parts.
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
1
2
5
4
3
6
7
8
2
9
11
10
1
12
1
13
COMMON DESCRIPTION QTY.
SPARE
PART NO.
1 SPRING (PREINSTALLED IN 3,11 & 12) 3 10794
2 HOSE SEAL (PREINSTALLED IN 3 & 9) 2 10134
3 VACUUM BODY (SPRING & HOSE SEAL INCLUDED) 1 11431
4 DEBRIS BAG 1 10788
5 VACUUM BODY COVER 1 11443
6 VACUUM HEAD (BRUSH INCLUDED) 1 11445
7 BRUSH 1 11446
8 FLAT VACUUM NOZZLE 1 11444
9 ADAPTOR (HOSE SEAL INCLUDED) 1 11447
10 TELESCOPING ALUMINUM SHAFT 1 10798
11 BRUSH HEAD ( SPRING INCLUDED) 1 11073
12 SKIMMER NET ( SPRING INCLUDED) 1 10796
13 VACUUM HOSE 1 10797
