(107) MODEL 635T FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/21/2013
107
SAVE THESE INSTRUCTIONS
English
Page 5
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
" * ": Optional.
When ordering parts, be sure to quote the model number and part numbers.
8
9
10 11 12 13 14
8
9
10 11
12
13
15
15
8*
9*
10*
11*
12*
13*
14*
15*
16*
REF. NO.
DESCRIPTION
QTY.
SPARE PART NO.
2
2
2
2
1
2
2
10747E
10262
10745
10256
10255
11235
11074
11437
11576
PLUNGER VALVE (#9, #10 & #15 INCLUDED)
HOSE O-RING
STEP WASHER
STRAINER NUT
FLAT STRAINER RUBBER WASHER
THREADED STRAINER CONNECTOR
ADJUSTABLE POOL INLET NOZZLE
VACUUM RELEASE VALVE
VACUUM RELEASE VALVE CAP (NOT SHOWN)
*
*
