134A
SAVE THESE INSTRUCTIONS
(134) MODEL CS8221/CS8231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/18/2011
English
Page 24
SSTTAATTIIOONNAARRYY MMOOUUNNTTIINNGG OOPPTTIIOONN
Some countries, especially in the European community, require the product
to be secured to the ground or to a base in a permanent upright position.
Check your local authorities to determine if there is a regulation in your
area regarding above-the-ground swimming pool filter-pumps. If yes, then
the product can be mounted to a platform using the two holes located in
the base. See drawing below.
The product can be mounted on a cement base or onto a wooden platform
to prevent accidental falling over. Total assembly must exceed 18kg. The
European norm EN 60335-2-41 requires this product be secured to the
ground or to a base.
1. The mounting holes are 6.4 mm in diameter and spaced 506 mm apart.
2. Use two bolts and lock nuts with a maximum of 6.4 mm in diameter.
5
0
6 mm
SALTWATER SYSTEM/FILTER PUMP STATIONARY MOUNTING
OPTION
