263
PO
S AVE THESE INSTRUCTIONS
(263PO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 07/16/2014
English
When ordering parts, be sure to quote the model number and part numbers.
PARTS (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
Page 6
REF. NO. DESCRIPTION QTY.
PART NO.
1 CONTROL BASE 1 11931
2 CONTROL BASE BACK COVER 1 11719
3 CONTROL PANEL (INCLUDED #4 ) 1
11930
4 CONTROL PANEL BOLT 3 11024
5 CONTROL BASE INFLATION CAP 1 11831
6 CONTROL PANEL BOLT WRENCH 1 11053
7 SPA/COVER INFLATION HOSE 1 11830
8 SPA CONTROL INLET/OUTLET O-RING 2 11699
9 SPA CONTROL AIR INLET O-RING 1 11687
10 SPA DRAIN PLUG 1 11696
11 SPA DRAIN VALVE ADAPTOR 1 11713
12 FILTER CARTRIDGE HOUSING 2 11798
13 FILTER CARTRIDGE 2 11692
14 FILTER CARTRIDGE HOUSING LID 2 11797
15 INLET/OUTLET PLUG 3 11739
16 SPA TUB 1
11879
17 SPA COVER 1
11878
18
SPA COVER INFLATABLE BLADDER (PRE-INSTALLED IN SPA COVER)
1
11884
19 GROUND CLOTH 1
11933
20 CHEMICAL DISPENSER 1
11614
21 TEST STRIPS 1 11855
22 WRENCH 1 11742
23 PRESSURE GAUGE 1 11741
24 SUCTION FITTING 3 11695
25 INFLATION HOSE ADAPTOR 1 11829
26 MALE BUCKLE 8 11698
27 FEMALE BUCKLE
8
11799
28 DEFLATION OUTLET CAP 1 11934
29 DEFLATION HOSE ADAPTOR 1 11935
30 SPA FILTER MOTOR 1 11885
SPA SUCTION FITTING
Self-contained spa fi ttings. – For multiple outlet use only. – Wall mounting only.
Replace suction fi ttings within 3 installed year. – Tool required: screwdriver.
Spa suction fi tting maximum fl ow rate: 8.5 gpm (510 gph)
•
Check suction strainer fi tting and fasteners for damage or tampering before each use of the spa.
•
For service and winterization instructions refer to “Maintenance” and “Storage” sections.
•
Read and follow all instructions, save these instructions for future reference.
