CHARGE/RECHARGE INSTRUCTIONS
Charging the pump by AC adapter using household 220-240 AC voltage:
1. The pump must be charged for 10 hours or overnight with AC adapter powered by
household 220-240 AC voltage.
2. Plug the AC adapter power cord into the air pump power receptacle
(FIG. 1)
.
3. Plug the other end of the AC adapter power cord into a household 220-240 Volt AC
electrical outlet
(FIG. 2)
.
4. Slide the switch to “ ” position to charge/recharge the batteries
(FIG. 3)
.
5. Initial Charge: Charge the pump for ten
(10)
hours or overnight with household AC
voltage.
6. When the pump is fully charged, remove the power cord
(FIG. 4)
.
Charging the pump using a standard automobile 12 Volt
DC power source:
1. The pump must be charged for 1 hour with 12 Volt DC
power source.
2. Plug the 12 Volt DC power cord into the air pump power receptacle
(FIG. 5)
.
3. Attach the DC power cord plug into a standard 12 Volt DC automobile cigarette lighter
or 12V DC accessory outlet
(FIG. 5)
.
4. Slide the switch to “ ” position to charge/recharge the batteries
(FIG. 3)
.
5. Charge: Charge the pump for 1 hour with 12 Volt DC power source.
6. When the pump is charged, immediately remove the power cord.
NOTE:
The LED light turns red during charging/recharging mode. If the LED light does
not light up, make sure the switch is in the “ ” position.
SAVE THESE INSTRUCTIONS
Page 3
FIG (3)
220~240V
110~120V
FIG (2)
√
FIG (1)
FIG (4)
FIG (5)
