21
6 Control
console
6.1
Control console layout
1) Speed
controller
2)
Battery charge indicator
3)
Status indicator (ON/OFF
and error codes)
4)
T
hrottle control lever, right
side
5)
Key switch (ON/OFF)
6)
Charger jack (located
underneath the key sw
itch)
7) Horn
8)
T
hrottle control lever, left
side
20
