3.1.2 Menu list
Different modules of IT8700 series electronic loads have different setting and
configuration menu according to different working modes.
Press key to enter menu setting, view the menu in VFD and use
and to scroll through the completely menu list as following. Press
key to enter the selected menu function, use and to
scroll through the VFD screen, press key to enter the under submenu,
press back to the previous menu selection page.
Setting menu
Press key to enter menu setting.
⚫ Setup menu list of
IT8732B/IT8733/IT8733B/IT8731/IT8732/IT8722/IT8723/IT8722B:
Setup
MODE
Select working mode
Const Current
Load works in CC mode
Const Voltage
Load works in CV mode
Const Resistance
Load works in CR mode
Const Power
Load works in CW mode
CC/CV RANGE
Switch the range
High Range
Low Range
I / V / R /W SET
Set the working current/voltage/resistance value
Vmax/Amax
Setup the maximum voltage value/maximum current value
Vmin/Amin
Setup the minimum voltage value/minimum current value
Vd=0.000V
Set the break-over voltage value( Only for CR-LED mode)
∫=2.500A/uS
Set the up slope (only CC mode available)
∫=2.500A/uS
Set the down slope(only CC mode available)
TRAN A=0.00A
Setup level A value
Ta=0.0005S
Setup level A width
TRAN B=0.00A
Setup level B value
Tb=0.0005S
Setup level B width
T MODE
Setup the transient mode
Continuous
Continuous mode
Pulse
Pulse mode
Toggle
Toggle mode
⚫ Setup menu list of
IT8732BP/IT8733P/IT8733BP/IT8731P/IT8732P/IT8722P/IT8723P/IT8722
BP:
Setup
MODE
Select working mode
Const Current
Load works in CC mode
Const Voltage
Load works in CV mode
Const Resistance
Load works in CR mode
Const Power
Load works in CW mode
CC/CV RANGE
Switch the range
High Range
Low Range
I / V / R / Pset
Set the working current/voltage/resistance value
Vmax/Amax
Setup the maximum voltage value/maximum current value
Vmin/Amin
Setup the minimum voltage value/minimum current value
SetupSetup
▲▲
▼▼
EnterEnter
▲▲
▼▼
EnterEnter
EscEsc
SetupSetup
