IVT Greenline E20 User Manual

61
Temperature ºC
k
ΩΩ
ΩΩ
Ω Temperature ºC
Temperature ºC
Sensor table
The table shows the resistance of all sensors at different temperatures.
-40 154,30 5 11,90 50 1,696
-35 111,70 10 9,33 55 1,405
-30 81,70 15 7,37 60 1,170
-25 60,40 20 5,87 65 0,980
-20 45,10 25 4,70 70 0,824
-15 33,95 30 3,79 75 0,696
-10 25,80 35 3,07 80 0,590
-5 19,77 40 2,51 85 0,503
0 15,28 45 2,055 90 0,430
k
ΩΩ
ΩΩ
Ω k
ΩΩ
ΩΩ
Ω
Model Greenline D14-E14 D16-E16 D20-E20 D25-25 D35 D40
Emitted /Supplied output at 0/35ºC (¹) kW 13,8/3,2 15,8/3,6 21/5,1 25,5/6,3 35,2/8,6 41,5/10,4
Emitted /Supplied output at 0/50ºC (¹) kW 13,5/4,6 15,4/5,2 20/7,1 24,8/8,7 34,7/12 40,9/14,3
Nominal flow distr. system l/s 0,46 0,53 0,69 0,85 1,19 1,41
Nominal flow collector system l/s 0,79 0,91 1,16 1,45 2,03 2,39
Permitted ext. press. drop distr. syst. kPa 43 41 45 40 65 62
Permitted ext. press. drop coll. syst. kPa 75 74 63 60 50 47
Electrical supply 400V, N3 three-phase 50 HZ
Electric boiler in three steps E-model kW 15,75 15,75 18 27 - -
5,6 / 9,0 / 15,75 5,6 / 9,0 / 15,75 6,7 / 11,3 / 18,0 9,0 / 18,0 / 27,0
Fuse size D-model AT 16 16 20 25 35 35
Fuse size E-model depending
on the electric boiler output
9.0 kW AT 25 25 - - - -
15.75 kW AT 35 35 - - - -
11.3 kW AT - - 35 - - -
18.0 kW AT - - 50 50 - -
27.0 kW AT - - - 63 - -
Recommended setting motor cutout A 9,6 10,8 13,7 16,4 23,4 26,5
Compressor Scroll
Starting current (LRA) A 59,5 70,5 98 120 175 175
Max outgoing heating transfer fluid ºC 55
Refrigerant quantity (R407C) kg 1,8 2,2 3,7 4,2 7,5 8,5
Connection, heating medium Cu 28 28 35 35 35 35
Connection, cooling medium Cu 35 35 42 42 42 42
Dimensions (WxDxH) mm 600x600x1500 700x750x1500 700x750x1500
Weight kg 180 180 210 210 230 230
(¹) Output data at 0/35ºC and 0/50ºC are stated in accordance with the European standard EN255. Additional heat not included.
Technical information
Table of selected output in display 5.2
The table shows the output available for various selections in display P5.2. If e.g. you have chosen
2/3 the output is in two steps. The first step is 5.6 kW and the second is 9.0kW.
Model
E14 and E16
Max output at 1/3
5.6 kW
Max output at 2/3
9.0 kW
Max output at 3/3
15.75 kW
E20
6.7 kW 11.3 kW 18.0 kW
E25 9.0 kW 18.0 kW 27.0 kW
