Jacobsen LF 3400 Dealer's Manual

2 CONTROLS
GB-6
2.2 CONTROLS ______________________________________________________________
A Tilt Steering Lever
B1 Parking Brake Lock
B2 Parking Brake Release
C Parking Brake
D
Mow Speed Stop
E Traction Pedal - Forward
F Traction Pedal - Reverse
G
Seat Adjustment
H Hydraulic Oil Cap/Dipstick
I Fuel Cap
J Air Cleaner Indicator
K Backlap Switch
L Alarm
M Controller / Fuses
N Hyd. Oil Level Light
O Hyd. Oil Level Switch
P Mower Lift Lever
Q Reel Switch
R 2 WD / 4 WD
S Light Switch
T Engine Throttle
U Cruise Control (Option)
V Ignition Switch
W Hour Meter
X Fuel Gauge
Y Warning Lights
Z Engine Coolant
Temperature
A
B
1
C
B
2
D
E
F
G
N
O
P
Q
R
S
T
U
V
H
I
J
W
X
Y
K
Z
L
M
5 Gang Control Panel
