QUICK START GUIDE
en-15
WARNING SLOPE ANGLE 25°
If the slope angle reaches 25º the screen will
display this warning indicating that at 25º the
front cutter deck will be lifted 4- 6 inches
above the ground to improve the stability and
all decks will stop rotation. An audible
warning will be given, the buzzer will sound
four times every 4 seconds and the red
LED’s will flash four times every 4 seconds.
This will continue until the machine has been
driven to an area of less than 16º.
Press the button below the to confirm the
fault.
WARNING OIL PRESSURE FAULT
When this screen is shown, the engine oil
pressure has decreased below the normal
level. If this happens during operation, or
does not go off when the engine is run at
more than 1000 rpm. Stop the engine and
check the oil level. Top up if necessary.
Press the button below the to confirm the
fault.
WARNING CLEAR RADIATOR SCREENS
When this screen is shown, the engine
temperature has risen above the normal
level.
Stop the engine and clean the radiator
screens.
The number in the top right of the screen
indicates the total number of faults recorded.
Press the button below the to confirm the
fault.
WARNING ENGINE FAULT
When this screen is shown, there is an
engine fault.Stop the engine as soon as
possible and contact your local Ransomes
Jacobsen Dealer
When this fault occurs the machine go’s into
limp-home mode.
The number in the top right of the screen
indicates the total number of faults recorded.
Press the button below the to confirm the
fault.
