Jacuzzi ESPREE 542 Series User Manual

Note: Unless otherwise specified, units are produced with left or right-hand versions.
Note: 1. The overall dimensions are nominal with a tolerance of +0 and -1/4".
2. *Add 1/4" to this dimension when roughing-in for 3-wall niche.
3. Measurements inside each unit represent cutout in floor to allow for drain/overflow.
4. All measurements are in inches. To convert to millimeters, multiply inches by 25.4.
10-13/16"
16"
2"
32"
*60"
14" x 4"
ESPREE 6032 WITH SKIRT
(Left hand shown)
60"
18"
2"
18" x 4"
36"
15-5/8"
ESPREE 6036
(Left hand only as shown)
60"
21"
2"
18" x 4"
42"
15-5/8"
ESPREE 6042
(Left hand only as shown)
ROUGH-IN
15-5/8"
ESPREE 7236
18" x 4"
(Left hand only as shown)
2"
72"
3
6"
18"
ESPREE 7242
15-5/8"
(Left hand only as shown)
21"
42"
2"
18" x 4"
*72"
ESPREE 6042 BM
21"
42"
2"
14'' x 4''
10-13/16"
(Left hand shown)
*60"
10-13/16"
16"
2"
32"
*60"
14-1/2" x 4"
ESPREE 6032
(Left hand only)
10-1/4"
16"
2"
32"
*60"
14" x 4"
ESPREE 6032 WITH SKIRT
(Left hand shown)
3
Jacuzzi Whirlpool Bath© U961000F 12/04

Jacuzzi ESPREE 542 Series Specifications
