Powered Subwoofer BASS15/16
MECHANICAL PARTS LIST
REF. NO. PART NO. DESCRIPTION QTY
1 BR1187 ALUM. BAR 4.8mmx12.7mmx40m 1
2 HS1102 HEAT SINK BASS15 1
3 FH1002 FUSE HOLDER 1/4x1-1/4 CHAS 1
4 SEE FUSES
5 LB1269 LABEL FOR HEATSINK FOR BASS15 1
7 MS1004 SILICONE GREASE #340 DOW
8 PM1366 GASKET FOR BASS20/15 1
9 TE1125 TERMINAL ULTRA FAST INS. 2
10 WI1637 WIRE #18 BLUE/WHITE TRACER 0.25FT
11 SC1194 SC 6-32x7/8 CUTT-THR HEX 1
12 WA1049 WASHER EXT. TOOTH #6 ZINC 3
13 XX1250 STRAIN RELIEF SPT-1 BLACK 1
15 SC1215 SC M3x1.25x10 PLAS-THR PAN 4
17 XX1174 AC CORD. 6FT UL/CSA APRO. 1
18 SP1020 SIL FOAM 3/8"Lx1/4"Wx3/16" 1
19 SP1073 SIL PAD TO-3P 1.0"x0.75" 2
20 XX1257 COVER PLASTIC JBL BASS15/20 1
21 XX1259 KNOB BLACK CUSTOM 1
22 SC1194 Sc 6-32x3/8 TAPT-THR HEX W 2
23 WA1032 WASHER PLAIN #6 ZINC FINISH 3
CT, LINE1, TE1175 TRMNL MALE TAB 0.032"x0.250" 3
LINE2
SPK1, SPK2 C01256 JACK SPEAKER QUAD PC 2
ELECTRICAL PARTS LIST
Capacitors
C1, C2 CP1545 CAP ALUM EL 4700uF 20% 50 2
C3, 20 CP1473 CAP CERAMIC 220pF 50V 2
C4, 24, 30, CP1415 CAP ALUM EL 2.2uF 20% 50V 6
31, 32,
33
C5 CP1528 SMD CAP 0.1uF 10% 50V X7R 1
C7 CP1578 CAP CERAMIC 0.1uF 10% 50V 1
C8, 10, 13 CP1552 SMD CAP 0.1uF 20% 100V Z5U 3
C9, 12 CP1417 CAP ALUM EL 22uF 20% 16V 2
C11 CP1495 CAP POLY FILM 0.1uF 5% 63V 1
C14, 16 CP1426 SMD CAP 0.1uF 20% 50V Z5U 2
C15 CP1621 SMD CAP 1.8nF 10% 100V X7R 1
C19, 28 CP1645 CAP AL EL 22uF 20% 63V 85 2
C21 CP1478 SMD CAP 330pF 5% 100V NPO 1
C22 CP1475 SMD CAP 33pF 5% 50V NPO 12 1
C23 CP1411 CAP ALUM EL 100uF 20% 16V 1
C1P CP1495 CAP POLY FILM 0.1uF 5% 63V P 1
REF. NO. PART NO. DESCRIPTION QTY
Diodes
CR1, 2, 3, DI1005 RECTIFIER 3A/200V 1N5401 4
4
D1, 2, 3, DI1132 SMD SWCH LL-34 PKG 1N4148 5
4, 5
Z1, 2 DI1150 SMD ZENER 15V 5% CP PKG 2
Fuses
F1(120V) FS1063 FAST BLOW 3A 250V 3AG 1
Integrated Circuits
IC1, 2, 3, IC1041 IC SMD DUAL J-FET NJM072B 5
4, 5 OP AMP
Resistors
J1, 2, 3, 4, RS1779 SMD RES ZERO Ω JUMPER 12 P 8
5, 6, 7,
10
R1, 2, 4, 5, RS1702 SMD RES 100KΩ 5% 1/8W 12 P 6
42, 46
R3, 8, 14, RS1701 SMD RES 10KΩ 5% 1/8W 120 12
18, 21,
23, 39,
45, 50,
52, 53,
54
R6, 7, 31 RS1700 SMD RES 1KΩ 5% 1/8W 12 3
R9 RS1962 SMD RES 61.9KΩ 1% 1/8W 120 P 1
R10 RS2081 SMD RES 121KΩ 1% 1/8W 12 P 1
R11 RS1800 SMD RES 150KΩ 5% 1/8W 12 P 1
R12 RS1716 SMD RES 33KΩ 5% 1/8W 120 1
R16, 49 RS1715 SMD RES 5.6KΩ 5% 1/8W 1 P 2
R17 RS1883 SMD RES 1.5KΩ 5% 1/8W 12 P 1
R19 RS1878 SMD RES 10Ω 5% 1/8W 120 P 1
R20, 40 RS1829 SMD RES 160Ω 5% 1/8W 12 P 2
R22, 33, 34 RS1705 SMD RES 4.7KΩ 5% 1/8W 12 P 3
R24, 47, 55 RS1767 SMD RES 1MΩ 5% 1/8W 120 P 3
R25 RS1831 SMD RES 7.5KΩ 5% 1/8W T/ P 1
R26, 28 RS1717 SMD RES 100Ω 5% 1/8W 12 P 2
R29 RS1790 RES F/CHIP 2.67kΩ 1% 1
R30 RS1711 SMD RES 220Ω 5% 1/8W 12 P 1
R35 RS1912 SMD RES 11KΩ 5% 1/8W 120 P 1
R37 RS1703 SMD RES 2.2KΩ 5% 1/8W 12 P 1
R43, 44 RS1968 SMD RES 2.2MΩ 5% 1/8W 12 P 2
R48 RS1710 SMD RES 3.3KΩ 5% 1/8W 12 P 1
R51 RS1992 SMD RES 390Ω, 1%, 1/8W, 1206 1
R56 RS1722 SMD RES 392Ω 1% 1/8W 12 P 1
R1P, R2P RS1868 RES. W/W 0.1Ω 5W 5% RAD P 2
R5P, 6P RS1916 RES. C/F 5.1Ω 5% 1/4W T/ P 2
R7P RS1245 RES. C/F 220Ω 5% 1/4W T P 1
BASS 15 PARTS LIST
