Powered Subwoofer BASS15/16
BASS 16 PARTS LIST
MECHANICAL PARTS LIST
REF. NO. PART NO. DESCRIPTION QTY
1 BR1187 ALUM. BAR 4.8mmx12.7mmx40m 1
2 HS1102 HEAT SINK BASS15 1
3 FH1002 FUSE HOLDER 1/4x1-1/4 CHAS 1
7 MS1004 SILICONE GREASE #340 DOW
8 PM1366 GASKET FOR BASS20/15 1
11 SC1194 SC 6-32x7/8 CUTT-THR HEX 3
12 WA1049 WASHER EXT. TOOTH #6 ZINC 3
13 XX1250 STRAIN RELIEF SPT-1 BLACK 1
15 SC1215 SC M3x1.25x10 PLAS-THR PAN 4
16 MD0105011 POWER MODULE BASS15 1
18 SP1020 SIL FOAM 3/8"Lx1/4"Wx3/16" 1
19 SP1073 SIL PAD TO-3P 1.0"x0.75" 2
20 XX1257 COVER PLASTIC JBL BASS15/20 1
21 XX1259 KNOB BLACK CUSTOM 1
23 LB1291 LABEL FOR HEATSINK BASS16 (120V) 1
24 SA0116121 MAIN PCB ASSEMBLY 1
25 HA1085 AC CORD. 6FT UL/CSA APRO. 1
26 HS1151 HEAT SINK, JBL, SUBWOOFER, BASS16 1
27 FH1003 FUSE HOLDER 5x20mm 1
29 SC1192 SC 6-32x3/4 TAPT-THR HEX 1
31 LB1293 LABEL FOR HEATSINK BASS16 (230V) 1
32 SA0116231 MAIN PCB ASSEMBLY (230V) 1
33 HA1099 AC CORD. 6FT UL/CSA APRO. (230V) 1
34 SC1194 SC 6-32x3/8 CUTT-THR HEX 4
35 WA1032 WASHER PLAIN #6 ZINC FINISH 4
CT, LINE1, TE1175 TRMNL MALE TAB 0.032"x0.250" 3
LINE2
SPONGE SP1082 SPONGE W/ADHESIVE L=1/4", W=1/4" 2
Thick=3/16"
SPK1, SPK2 C01256 JACK SPEAKER QUAD PC 2
LB1265 BAR CODE TRACEABILITY LABEL 2
ELECTRICAL PARTS LIST
REF. NO. PART NO. DESCRIPTION QTY
Capacitors
C1, C2 CP1545 CAP ALUM EL 4700uF 20% 50 2
C2P, 3P CP1480 SMD CAP 470pF 5% 100v NPO 2
C3, 20 CP1473 SMD CAP 220pF 10% 50V 2
C4, 24, 30, CP1415 CAP ALUM EL 2.2uF 20% 50V 6
31, 32,
33
C5, 7, 11 CP1495 CAP POLY FILM 0.1uF 5% 63V 3
REF. NO. PART NO. DESCRIPTION QTY
C6, 5P, 17 CP1579 CAP ALUM EL 33uF 20% 16V NP 3
C8, 10, 13 CP1552 SMD CAP 0.1uF 20% 100V Z5U 4
4P
C9, 12, 27 CP1417 CAP ALUM EL 22uF 20% 16V 4
29
C14, 16 CP1426 SMD CAP 0.1uF 20% 50V Z5U 2
C15 CP1534 SMD POLY FILM 15nF 5% 63V 1
C19, 28 CP1645 CAP AL EL 22uF 20% 63V 85 2
C21 CP1478 SMD CAP 330pF 5% 100V NPO 1
C22 CP1475 SMD CAP 33pF 5% 50V NPO 12 1
C23 CP1411 CAP ALUM EL 100uF 20% 16V 1
CIP CP1528 SMD CAP 0.1uF 10% 50V X7R 1
CX1, X2, CP1844 SMD CAP CERAMIC 0.01uF 10% 4
X3, X4 200V X7R 1206 T/R
Diodes
CR1-4 DI1005 DIODE 3A/200V 1N5401 4
D1-5 DI1132 SMD DIODE 1N4148 5
Z1, 2 DI1150 SMD ZENER 15V 5% CP PKG 2
Fuses
F1 (120V) FS1063 FUSE FAST BLOW 3A 250V ACG 1
F1 (230V) FS1067 FUSE FAST BLOW 2A 250V ACG 1
F2 870-5460 SLO-BLOW 6A GMC 5x20mm 250V 1
Integrated Circuits
IC1, 2, 3, IC1041 IC SMD DUAL J-FET NJM072B 5
4, 5 OP AMP
Resistors
J1-16 RS1779 SMD RES ZERO Ω JUMPER 120 P 16
R1, 2, 4, 5, RS1702 SMD RES 100KΩ 5% 1/8W 120 P 9
11, 24,
46, 57,
58
R1P, R2P RS1868 RES. W/W 0.1Ω 5% 5W 2
R3, 8, 14, RS1701 SMD RES 10KΩ 5% 1/8W 120 15
18, 21,
23, 27,
32, 38,
39, 45,
50, 52,
53, 54
R3P RS1994 RES C/F 100Ω 5% 1/4W T/R 1
R5P, 6P RS1916 RES. C/F 5.1Ω 5% 1/4W T/R 2
R6, 7, 31 RS1700 SMD RES 1KΩ 5% 1/8W 120 3
R7P RS1245 RES. C/F 220Ω 5% 1/4W T/R 1
R9 RS1962 SMD RES 28KΩ 1% 1/8W 120 P 1
R10 RS2162 RES F/CHIP 60.40KΩ 1% 1/8W 120 P 1
R12 RS1716 SMD RES 33KΩ 5% 1/8W 120 1
