JBL Cinema Sound CSS10 User Manual

CSS10 Electrical Parts List
Part Number Description Qty Reference Designators
PREAMP PCB
Resistors
110-16102j26 CARBON RESISTOR 1K 1/6W ±5% CF 26mm 4 R213,R214,R215,R254
110-16103j26 CARBON RESISTOR 10K 1/6W ±5% CF 26mm 18
R9
,
R10
,
R11
,
R212
,
R216
,
R217
,
R220
,
R221
,
R22
2,
R225,R228,R229,R230,R232,R240,R248,R260
110-16104j26 CARBON RESISTOR 100K 1/6W ±5% CF 26mm 3 R231,R263,R266,
110-16105j26 CARBON RESISTOR 1M 1/6W ±5% CF 26mm 1 R259
110-16122j26 CARBON RESISTOR 1.2K 1/6W ±5% CF 26mm 1 R265
110-16151j26 CARBON RESISTOR 150Ω 1/6W ±5% CF 26mm 1 R253
110-16154j26 CARBON RESISTOR 150K 1/6W ±5% CF 26mm 1 R252
110-16183j26 CARBON RESISTOR 18K 1/6W ±5% CF 26mm 1 R262
110-16205j26 CARBON RESISTOR 2M 1/6W ±5% CF 26mm 1 R257
110-16223j26 CARBON RESISTOR 22K 1/6W ±5% CF 26mm 4 R247,R255,R256,R227
110-16472j26 CARBON RESISTOR 4.7K 1/6W ±5% CF 26mm 1 R258
110-16473j26 CARBON RESISTOR 47K 1/6W ±5% CF 26mm 5 R219,R249,R250,R251,R264
110-16512j26 CARBON RESISTOR 5.1K 1/6W ±5% CF 26mm 1 R211
116-161002f26 METAL FILM RESISTOR 10K 1/6W ±1% MF 26mm 1 R237
116-161212f26 METAL FILM RESISTOR 12.1K 1/6W 1% MF 26mm 2 R223,R224
116-162152f26 METAL FILM RESISTOR 21.5K 1/6W 1% MF 26mm 1 R238
116-162202f26 METAL FILM RESISTOR 22.0K 1/6W ±1% MF 26mm 1 R226
116-162801f26 METAL FILM RESISTOR 2.80K 1/6W 1% MF 26mm 1 R234
116-164422f26 METAL FILM RESISTOR 44.2K 1/6W 1% MF 26mm 1 R233
115-h503a102 VAR RES RV16AE-20B2-15K-A54-104(A50K) LEVEL 1 VR201
Capacitors
129-a103j633 METALIZED CAP 10NF 63V 2 C218,C217
129-a104j633 METALIZED CAP 0.1U 63V ±5% MSC 1 C215
129-a223j633 METALIZED CAP 0.022U 63V ±5% MSC 1 C223
129-a224j633 METALIZED CAP 0.22uF 63V ±5% MSC 1 C224
129-a474j633 METALIZED CAP 0.47U 63V ±5% MSC 3 C221,C222,C216
130-2b221k503 DISC CAPACITOR 220P 50V ±10% 9
C207
,
C208
,
C210
,
C211
,
C212
,
C214
,
C220
,
C230
,
C249
130-2b470k503 DISC CAPACITOR 47P 50V ±10% 1 C229
130-3f104z503 DISC CAPACITOR 0.1U 50V +80/-20% 8 C232,C242,C244,C245,C246,C252,C254,C256
130-sl101k503 DISC CAPACITOR 100P 50V SL ±10% 1 C6
135-3105m50 ELECTROLYTIC CAP 1U 50V ±20% 1 C228
135-3106m50 ELECTROLYTIC CAP 10uF 50V ±20% 8 C206,C213,C219,C231,C241,C243,C251,C253
135-3107m16 ELECTROLYTIC CAP 100uF 16V ±20% 1 C234
135-3226m16 ELECTROLYTIC CAP 22U 16V ±20% 1 C225
135-3226m50 ELECTROLYTIC CAP 22U 50V ±20% 3 C225,C505,C506
135-3227m16 ELECTROLYTIC CAP 220U 16V ±20% 1 C233
Semiconductors
192-027c1815gr TRANSISTOR 2SC1815GR NPN 4 Q201,Q206,Q207,Q208
197-031n4148 DIODE 100mA 75V SIGNAL 1N4148 ROHM 9
D201
,
D202
,
D207
,
D208
,
D211
,
D212
,
D214
,
D215
,
D216
199-15000335 ZENER DIODE 3.3V 1/2W 52mm 1 D213
190-06m4558d I.C. OPA 4558D DIP DUAL OP-AMP 1 U203
190-16tl074cn I.C TL074CN ST QUAD OP-AMP 2 U201,U202
195-10204hgw LED 204HGW 3￠ RED/GREEN 1 D209
Miscellaneous
162-50159201 WIRE ASS'Y 2PIN 150mm WHT/RED 1 P1 TO PSW
174-0rca108gv RCA-108GV purple JK203 LFE 1 JK201
CSS10 Cinema Sound
11

JBL Cinema Sound CSS10 Specifications

General

Brand	JBL
Model	Cinema Sound CSS10
Category	Amplifier
Language	English
