Part Number Description Qty Reference Designator
Note on Numbering Sequence, all components: "D1~7" (tilde mark) means D1,2,3,4,5,6,7.
but "D136-D436" (hyphen) means D136,236,336,436"
Main PCB
220880243 RESISTOR RD 1/8W 24K 2 R123 R223
220880272 RESISTOR RD 1/8W 2.7K 1 R24
220880302 RESISTOR RD 1/8W 3K 4 R9 R18 R39 R38
220880363 RESISTOR RD 1/8W 36K 1 R51
220880391 RESISTOR RD 1/8W 390Ω 4 R111-R411
220880392 RESISTOR RD 1/8W 3.9K 1 R13
220880470 RESISTOR RD 1/8W 47Ω 8 R145-R445 R158-R458
220880472 RESISTOR RD 1/8W 4.7K 4 R146-R446
220880473 RESISTOR RD 1/8W 47K 10 R1 R34 R101-R401 R102-R402
220880474 RESISTOR RD 1/8W 470K 1 R44
220880562 RESISTOR RD 1/8W 5.6K 4 R155-R455
220880563 RESISTOR RD 1/8W 56K 9 R52 R109-R409 R110-R410
220880682 RESISTOR RD 1/8W 6.8K 2 R46 R16
220880821 RESISTOR RD 1/8W 820Ω 4 R153-R453
230881002 RESISTOR MF 1/8W 10K 1% 1 R48
230881003 RESISTOR MF 1/8W 100K 1% 4 R105-R405
230881052 RESISTOR MF 1/8W 10.5K 1% 1 R47
230882202 RESISTOR MF 1/8W 22K 1% 1 R8
230884751 RESISTOR MF 1/8W 4.75K 1% 6 R213 R413 R112-R412
230884991 RESISTOR MF 1/8W 4.99K 1% 2 R113 R313
220220220 RESISTOR RD 1/2W 22Ω 1 R37
220220470 RESISTOR RD 1/2W 47Ω 2 R33 R32
220880472 RESISTOR RD 1/8W 4.7K 4 C103~403
231100101 RESISTOR 1Ws 100Ω 1 R31
232XL502J CEMENT RESISTOR SQM 5Ws 0.2Ω 8 R149-R449 R150-R450
202G09B23 Variable Resistor B20K 20% H=15L=9 Input Lev. 2 VR101 VR201
Capacitors
31K510010 CERAMIC CAPACITOR C/C NPO 10pF 100V K 4 C101-C401
31Z510305 CERAMIC CAPACITOR C/C Y5V 10000pF 50V Z 1 C35
31Z510410 CERAMIC CAPACITOR C/C Y5V 0.1uF 100V Z 8 C6~9 C10 C11 C31 C32
31J547010 CERAMIC CAPACITOR C/C NPO 47pF 100V J 18
C12 C13 C136-C436 C142-C442 C137-C437
C105-C405
31J568125 CERAMIC CAPACITOR C/C Y5E 680pF 250V K 1 C22
32J510410 M/C M/C 0.1uF 100V J 8 C143-C443 C138-C438
32J568210 M/C M/C 0.0068uF 100V J 1 C20
340Z10625 Electrolytic Cap 10uF 25V 5*11 6 C112 C212 C129-C429
340Z10716 Electrolytic Cap 100uF 16V 5*11 10 C4 C19 C27~30 C141-C441
340Z22550 Electrolytic Cap 2.2uF 50V 5*11 3 C3 C34 C33
340Z22616 Electrolytic Cap 22uF 16V 1 C21
340Z22625 Electrolytic Cap 22uF 25V 5*11 9 C2 C100-C300 C402 C104-C404
340Z47625 Electrolytic Cap 47uF 25V 5*11 3 C5 C36 C14
370Z10550 Electrolytic Cap 1uF 50V 5*11 3 C239 C339 C439
370Z10716 Electrolytic Cap 100uF 16V 8*12 1 C18
370Z22616 Electrolytic Cap 22uF 16V NP 1 C1
390Z22625 Electrolytic Cap 22uF 25V 4*7 4 C102 C202 C302 C400
340T10750 Electrolytic Cap 100uF 50V 8*13 8 C135-C435 C140-C440
341T22835 Electrolytic Cap 2200uF 35V 16*26 105C 4 C23~26
341T10835 Electrolytic Cap 1000uF 35V 13*26 105C 3 C15~17
370Z10550 Electrolytic Cap 1uF 50V 5*11 1 C139
370Z10625 Electrolytic Cap 10UF/25V 5*11 4 C103-C403
Miscellaneous
261T05103 THERMISTOR NTC THERMISTORD103J 10K 2 RTH1 RTH2
173T00102 INDUCTOR 102UH 1 JP89
401T25040 COPPER BAR φ2.5*40m/m H=20 1
CS Series 60.4
