CS 60.4 Electrical Parts List
Part Number Description Qty Reference Designator
Note on Numbering Sequence, all components: "D1~7" (tilde mark) means D1,2,3,4,5,6,7.
but "D136-D436" (hyphen) means D136,236,336,436"
Main PCB
Semiconductors
124TN4401 Transistor TR MOTOROLA 2N4401 NPN 18
Q2 Q4 Q5 Q16 Q17,Q138-Q438,Q140-Q440
Q135-Q435 Q143
124TN4403 Transistor TR MOTOROLA 2N4403 PNP 11 Q6 Q9 Q10 Q136-Q436 Q137-Q437
124T0SA06 Transistor
TR MOTOROLA MPSA06 80V NPN
4 Q145-Q445
125T0C945 Transistor TR NEC 2SC945P 0.1A60V NPN 4 Q144-Q444
126TSB647 Transistor 2SB647A PNP 6 Q7 Q8 Q146-Q446
126TSD667 Transistor 2SD667A NPN 5 Q14 Q141-Q441
129T0J109 Transistor J109 1 Q1
131TN4148 DIODE DIODE NS1N4148HSS150MA 13 D1~7 D11~16
133T0J5B6 ZINER DIODE DIODE NECRD5.6JSB ZNR5.6V 1 ZD1
133T0011B ZINER DIODE DIODE NEC RD11EB3 11V 1 ZD2
133T0015B ZINER DIODE DIODE NEC RD15EB3 15V 2 ZD3 ZD4
155TTL431 IC DIP3 TL431 adjustable shunt regulator 1 Q3
124T0SA56 Transistor
TR MOTOROLA MPSA56 80V PNP
4 Q139-Q439
124TN4401 Transistor TR MOTOROLA 2N4401 NPN 3 Q243 Q343 Q443
134TN4002 RECTIFIER DIODE DIODE 1N4002 RET1.0A100V 8 D135-D435 D136-D436
134TN5402 RECTIFIER DIODE DIODE 1N5402 ET3.0A100V 1 D9
151T04558 IC SIP8 JRC MC4558 Dual Op-Amp 1 IC202
154T04558 IC DIP8
JRC or ROHM BA4558 Dual O
p
-Am
p
6 IC101-IC401 102-402, 203, 403
154LM358N IC DIP8 DIP8 LM358N Dual Op-Amp 1 IC2
158TTL494 IC DIP16 NEC UPC494 or TI TL494 PWM 1 IC1
123TRFZ48 Transistor IR IRFZ48V MOSFET 4 Q1~13,Q15
128TKD718 Transistor KD718 NPN 4 Q142-Q442
128TKB688 Transistor KB688 PNP 4 Q147-Q447
135T1620C DIODE DIODE MOTOROLA 1620CT 1 D8
135T1620R DIODE DIODE MOTOROLA 1620CTR 1 D10
Resistors
22022047A RESISTOR RD 1/2W 4.7Ω 4 R152-R452
220440101 RESISTOR RD 1/4W 100Ω 4 R25 R26 R28 R29
220440103 RESISTOR RD 1/4W 10K 4 R154-R454
220440272 RESISTOR RD 1/4W 2.7K 4 R151-R451
220880000 RESISTOR RD 1/8W 0Ω 29
JP1 JP18 JP24 JP30 JP35~39 JP41~51 JP53
JP86 JP101~103 R103-R403
220880101 RESISTOR RD 1/8W 100Ω 18
R11R27.R138-R438 R139-R439 R142-R442 R143
-
R443
220880102 RESISTOR RD 1/8W 1K 19
R7 R14 R15 R137-R437 R156-R456 R157-R457
R136-R436
220880103 RESISTOR RD 1/8W 10K 11 R135-R435 R10 R19 R20 R108-R408
220880104 RESISTOR RD 1/8W 100K 8 R2~6 R12 R124 R224
220880123 RESISTOR RD 1/8W 12K 1 R17
220880153 RESISTOR RD 1/8W 15K 2 R49 R50
220880154 RESISTOR RD 1/8W 150K 2 R43 R42
220880183 RESISTOR RD 1/8W 18K 9 R35 R140-R440 R141-R441
220880202 RESISTOR RD 1/8W 2K 2 R40 R41
230884421 RESISTOR MF1/8W 4.42K 1% 4 R144-R444
220880204 RESISTOR RD 1/8W 200K 1 R23
220880205 RESISTOR RD 1/8W 2M 1 R22
220880221 RESISTOR RD 1/8W 220Ω 4 R148-R448
220880222 RESISTOR RD 1/8W 2.2K 1 R36
220880223 RESISTOR RD 1/8W 22K 6 R45 R30 R100-R400
220880242 RESISTOR RD 1/8W 2.4K 4 R147-R447
CS Series 60.4
11
