2
Remote Contr
ol Dimensions
Installther
emotecontr
olonthewallaccor
dingtotheneedsofyouraudio
system,seegur
esA,B,C,andD.
Figure A: CSR-V Dimensions (EU V
ersion)
86mm
86mm
60mm
18.8mm
Figure B: CSR-2SV/CSR-3SV Dimensions
(EU V
ersion)
86mm
86mm
18.8mm
60mm
Figure C: CSR-V Dimensions (US V
ersion)
2.750
4.500
3.280
2.750
4.500
3.280
.723
.723
Figure D: CSR-2SV/CSR-3SV Dimensions
(US V
ersion)
2.750
4.500
3.280
2.750
4.500
3.280
.723
.723
3
5
Table of Contents
Declaration of Conformity
2
Remote Control Overview
3
Using the Remote Control
6
Specifications
7
Troubleshooting
7
4
