JBL GTO 4000 User Manual

9
REF. NO
REF. NO
PART NO.
PART NO.
DESCRIPTION
DESCRIPTIONQ'TY
Q'TY
SCREW
MNSC0423005
1
STT2 BH 3x5 NI-P
SCREW
MNSC0423008
7
STT2 BH 3x8 BK
SCREW
MNSC0433008
1
STT2 PH 3x8 BK
SCREW
MNSC0483010
3
STT2 FH 3x10 BK
SCREW
MNSC0423010
2
STT2 BH 3x10 BK
SCREW
MNSC0034014
8
SMP 4x14 NI-P
SCREW
MNSC0524020
4
STT1 BH 4x20 BK
POLY BAG(A)
MAPB0169150
1
VINYL,400.0x550.0x0.1T
POLY BAG(B)
MAPB0116610
1
VINYL,260.0x350.0x0.03T
POLY BAG(C)
MAPB0120970
1
VINYL 100.0x80.0x0.03t
INNER PAD
MOIN0873370
2
SW#1,338.0x105.0x95.0(BOX TYPE)
GIFT BOX
MAGB0468940
1
SW#1(B °ñ),460.0x343.0x110.0
CARTON BOX
MACB0269130
1
DW#2,475.0x470.0x368.0
MANUAL
1
ART PAPER
WARRANTY CARD
1
SERIAL NO
4Á¶
ART PAPER
QC LABEL
1
ART PAPER
STICKER
MDLA0784860
2
COLOR SHEET,326.0x37.5
WINDOW STICKER
1
JBL LOGO
CE LABEL
1
ART PAPER
SCOTCH TAPE
MOTA0118960
50Cm
Æø 20m/m
OPP TAPE
SILICAGEL
PAPER SPACER(A)
MOTA0218880
MOSG0147100
MOCU0441500
3.2m
1
1
BLUE COLOR
3g
FIBER,200.0x5.0x0.5T
4 Channel Power Amplifier
Gto 4000
Gto4000 Parts List
MECHANICAL
MAIN HEAT SINK
MAHSHC12300
AL/EXTRUDING L=326.0mm
1
FRONT PANEL
MAFPHC73140
EGI 1.2t
1
REAR PANEL
MARPHC73171
1
LED GUIDE
MALG0173193
EGI 1.2t
1
HEATPROOF ABS(GRAY)
TOP COVER
MATC0473202
1
ACRYLIC,3.0T(ORANGE)
TOP PLATE
MANPHC73220
2
PC,1.0T(CLEAR)
TR BRACKET(A)
TR BRACKET(B)
MABR0341240
MABR0341250
2
SBHG 200.0x22.5x2.0t
2
FIBER 200.0x25.5x2.0t
TR BRACKET CUSHION(A)
MOCU0248691
2
FIBER 200.0x22.0x1.0t
RUBBER CUSHION(A)
M0CU0141330
5
RUBBER 10.0x20.0x1.6t
RUBBER CUSHION(B)
M0CU0141670
4
RUBBER,PHI12xPHI5x2.0T
RUBBER CUSHION(C)
MOCU0140990
4
RUBBER,10.0x10.0x4t
CUSHION
MOCU0384560
2
FELT,18.0x6.0x0.3T
VOLUME KNOB
MAKB0142090
6
ABS/BK
PCB SUPPORT
MASU0584342
2
BSBM,PHI6.0(L=4.5m/m)
OPEN LUG(A)
MOOL0100010
9
2.5SQ
OPEN LUG(B)
MOOL0100020
2
5.5SQ
SILICON PAD
MASP0219010
400m/m
(SP1000)23x0.3T
FELT,12.0x7.0x0.3T
SCREW
MNSC0423006
10
STT2 BH 3x6 BK
SWITCH DECAL
MOSD0340170
3
