Section 2 - System Connection

SYSTEM CONNECTION

Please refer to the Typical Connection below to set up your audio system.

Analog Connection

Digital Connection

Mic 1&2 Mic 3

VOD Recorder

Amplifier

Right CH

Speaker

Left CH

Speaker

SurrR

Speaker

SurrL

Speaker

Center CH

Speaker

Subwoofer

Amplifier Amplifier

Typical Connection

NOTE:

1. Please ensure all the device are disconnected from power before connection.

2. Please ensure all the volume controls of each device are turned completed down.

3. Please always follow “Last On, First Off” while handling amplifiers or powered speakers.
