LS40 LS60 LS80
Frequency Response (–10dB) 42Hz – 40kHz 40Hz – 40kHz 35Hz – 40kHz
Frequency Response (–3dB) 50Hz – 38kHz 48Hz – 38kHz 46Hz – 38kHz
Power Handling (Continuous) 75W 75W 100W
Power Handling (Music) 150W 150W 200W
Power Handling (Peak) 300W 300W 400W
Max. Rec. Amplifier Power* 150W 150W 200W
Sensitivity (2.83V/1m) 87dB 87dB 90dB
Crossover Frequency 2.6kHz, 7kHz; 24dB/octave 400Hz, 6dB/octave,† 400Hz, 6dB/octave,†
2kHz, 8kHz; 24dB/octave 2.5kHz, 8kHz; 24dB/octave
Nominal Impedance 6 Ohms 6 Ohms 6 Ohms
Low-Frequency Transducer(s) 6-1/2" (165mm) Dual 6-1/2" (165mm) Dual 8" (200mm)
with cast-aluminum frames with cast-aluminum frames with cast-aluminum frames
High-Frequency Transducer 2" (50mm) Pure-titanium 2" (50mm) Pure-titanium 2" (50mm) Pure-titanium
compression driver, compression driver, compression driver,
Bi-Radial Horn
®
. Bi-Radial Horn
®
Bi-Radial Horn
®
Ultrahigh-Frequency Transducer 3/4" (19mm) Polyester-film 3/4" (19mm) Polyester-film 3/4" (19mm) Polyester-film
ring-radiator, ring-radiator, ring-radiator,
neodymium magnet; neodymium magnet; neodymium magnet;
EOS waveguide EOS waveguide EOS waveguide
Dimensions (H x W x D) 19-7/16" x 8-3/4" x 13-1/2" 39-1/2" x 8-3/4" x 13-1/2" 43-1/2" x 10-3/16" x 16-1/2"
(493mm x 222mm x 343mm) (1004mm x 222mm x 343mm) (1104mm x 259mm x 418mm)
Dimensions (H x W x D) 19-5/8" x 8-3/4" x 13-1/2" 40" x 8-3/4" x 13-1/2" 44" x 10-3/16" x 16-1/2"
(with feet and pad) (499mm x 222mm x 343mm) (1017mm x 222mm x 343mm) (1117mm x 259mm x 418mm)
Weight per Speaker 29.8 lb (13.5kg) 58.6 lb (26.6kg) 78.5 lb (35.6kg)
(net weight)
LS CENTER
Frequency Response (–10dB) 50Hz – 40kHz
Frequency Response (–3dB) 85Hz – 38kHz
Power Handling (Continuous) 75W
Power Handling (Music) 150W
Power Handling (Peak) 300W
Max. Rec. Amplifier Power* 150W
Sensitivity (2.83V/1m) 88dB
Crossover Frequency 2.5kHz, 9kHz; 24dB/octave
Nominal Impedance 6 Ohms
Low-Frequency Transducers Dual 6-1/2" (165mm)
with cast-aluminum frames
High-Frequency Transducer 2" (50mm) Pure-titanium
compression driver,
Bi-Radial Horn
®
.
Ultrahigh-Frequency Transducer 3/4" (19mm) Polyester-film
ring-radiator,
neodymium magnet;
EOS waveguide
Dimensions (H x W x D) 8-1/2" x 26-1/2" x 9-1/4"
(217mm x 672mm x 235mm)
Dimensions (H x W x D) 9" x 26-1/2" x 9-1/4"
(with feet and pad) (230mm x 672mm x 235mm)
Weight per Speaker 31.7 lb (14.4kg)
(net weight)
* The maximum recommended amplifier power rating will ensure
proper system headroom to allow for occasional peaks. We do not
recommend sustained operation at these maximum power levels.
† High-pass crossover for one of the two low-frequency transducers only.
SPECIFICATIONS
4
Declaration of Conformity
We, Harman Consumer Group, Inc.
2, route de Tours
72500 Château du Loir
France
declare in own responsibility that the products described
in this ownerʼs manual are in compliance with technical
standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Laurent Rault
Harman Consumer Group, Inc.
Château du Loir, France 01/08
