troubleshooting your jbl on stage micro II
Technical Specications
Symptom Possible Problem Solution
Sound Quality
Frequency Response:
70Hz – 20kHz
Power Consumption:
10W Maximum
Power Input:
6V/1.5A
JBL On Stage Micro II Transducer:
(2) 1” Full range per channel
Dimensions:
Diameter – 6” (150mm)
Height – 1-3/4” (38mm)
System Weight:
2.22 lb (1.01kg)
Battery:
Size – AAA (4 pcs.)
Type – Alkaline, NiMh
DO NOT MIX BATTERY TYPES.
DO NOT MIX CHARGED AND
PARTIALLY CHARGED BATTERIES.
BATTERIES WILL NOT RECHARGE
WHILE IN JBL ON STAGE MICRO II.
No sound from the JBL
On Stage Micro II speaker
system
No power to the system
Power adapter plug is not inserted
correctly
Ensure that the power supply is connected to a live
power source and properly connected to the JBL
On Stage Micro II. Note: When the JBL On Stage Micro II is
powered, a green power LED on the JBL On Stage Micro II
should light up.
No volume or low volume Touch the volume “Up” (+) pad on the volume control to
unmute and/or increase the system volume level.
Note: Touching the volume “Down” (–) pad lowers the
system volume. Touching both the (+) and (–) volume
control pads at the same time will mute the system.
Input source is low Increase the volume level on the audio source device.
Low or drained batteries Replace the batteries.
iPhone/iPod is paused Press the Play button on the iPhone/iPod or remote
control.
iPhone/iPod is paused (battery-
only mode)
Note: If the iPhone/iPod is paused more than 10 minutes,
press the JBL On Stage Micro II Power button to turn the
unit back on. Press either (+) or (–) to unmute.
If you have any questions or need further assistance, please visit www.jbl.com.
These specications are subject to change without notice.
