Typical System Configuration
4
Vehicle Battery
Chassis Ground
Ignition
Switch
CD Player or Changer
Cassette/CD Tuner
(Head Unit)
Power Ground
Speakers
Speakers
60 Amp (Not Included)
Main +12V
Line
Level
Input
Remote On/Off
Remote Antenna
Power Supply
Antenna Motor Ground
Remote On/Off
Black - Power Ground
Red - Main +12V
Black Power
Antenna Input
Power
Antenna
Cassette/Receiver
Power Supply
Wires
Fuse
Fuse
Fuse
Power
Antenna
Relay
Multichannel Automotive Amplifier
p80.4
